This two-story barndominium plan has 3,360 square feet of living space, not counting the garage, on a 63'-4" × 43'-4" footprint. It has six bedrooms and four baths. The primary suite and a guest bedroom are on the ground floor, so the main level works on its own for daily living.
From the foyer, the 30'-0" × 14'-7" great room sits next to the 11'-3" × 10'-8" dining area and the 19'-3" × 10'-4" kitchen with island. The mudroom (7'-2" × 10'-9"), pantry (5'-2" × 10'-9") and laundry (6'-2" × 10'-9") share the same depth, which keeps the service rooms in one run beside the 22'-1" × 26'-5" shop garage. Upstairs, a 5'-10" × 28'-4" hall connects four bedrooms, two baths and a 22'-1" × 12'-7" loft.
Layout highlights
- Primary bedroom is 14'-4" × 15'-3", with an 8'-6" × 7'-0" walk-in closet and a bath.
- Great room measures 30'-0" × 14'-7" and opens to the dining area and kitchen.
- Kitchen with island is 19'-3" × 10'-4", with a 5'-2" × 10'-9" pantry.
- Shop garage is 22'-1" × 26'-5", with a 7'-2" × 10'-9" mudroom.
- Upstairs loft is 22'-1" × 12'-7", served by a 5'-10" × 28'-4" hall.
Room sizes
| Room | Level | Size | Area |
|---|---|---|---|
| Foyer | 1 | 6'-8" × 10'-0" | 67 sq ft |
| Shop Garage | 1 | 22'-1" × 26'-5" | 583 sq ft |
| Great Room | 1 | 30'-0" × 14'-7" | 437 sq ft |
| Walk-in Closet | 1 | 8'-6" × 7'-0" | 59 sq ft |
| Stair | 1 | 8'-6" × 7'-10" | 66 sq ft |
| Primary Bedroom | 1 | 14'-4" × 15'-3" | 219 sq ft |
| Ground Hall | 1 | 23'-3" × 3'-10" | 90 sq ft |
| Primary Bath | 1 | 7'-4" × 12'-11" | 95 sq ft |
| Guest Bath | 1 | 7'-4" × 6'-2" | 45 sq ft |
| Mudroom | 1 | 7'-2" × 10'-9" | 77 sq ft |
| Pantry | 1 | 5'-2" × 10'-9" | 56 sq ft |
| Laundry | 1 | 6'-2" × 10'-9" | 66 sq ft |
| Kitchen with Island | 1 | 19'-3" × 10'-4" | 199 sq ft |
| Guest Bedroom | 1 | 11'-3" × 10'-5" | 118 sq ft |
| Dining | 1 | 11'-3" × 10'-8" | 120 sq ft |
| Stair | 2 | 7'-8" × 7'-10" | 60 sq ft |
| Upper Hall | 2 | 5'-10" × 28'-4" | 166 sq ft |
| Bedroom 2 | 2 | 15'-11" × 9'-4" | 148 sq ft |
| Bedroom 3 | 2 | 15'-11" × 9'-5" | 150 sq ft |
| Bedroom 5 | 2 | 15'-11" × 8'-10" | 140 sq ft |
| Loft | 2 | 22'-1" × 12'-7" | 279 sq ft |
| Upper Bath 1 | 2 | 7'-8" × 7'-0" | 54 sq ft |
| Upper Bath 2 | 2 | 7'-8" × 8'-10" | 68 sq ft |
| Bedroom 4 | 2 | 7'-8" × 16'-6" | 127 sq ft |
Who this plan suits
This plan suits large or multigenerational families who want a ground-floor primary suite, a guest room, and four more bedrooms upstairs. It needs a lot that fits the 63'-4" × 43'-4" footprint plus setbacks, driveway access to the shop garage and room for the front porch.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Two-story barndominium for a large family: ground floor primary suite, guest bedroom, open great room, kitchen with island and pantry, laundry, mudroom, attached shop garage; upstairs 4 bedrooms, 2 baths and a loft, about 3,600 sq ft of living space.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a 6 bedroom barndominium floor plan?
It is a barndominium layout that combines living space with a shop or garage under a barn-style structure, with six bedrooms. In this plan, two bedrooms are on the ground floor and four are upstairs, across 3,360 square feet of living space.
What affects the lot and build cost of this plan?
The two-story, 63'-4" × 43'-4" footprint is compact for six bedrooms, but it needs a lot with enough depth and width for setbacks and garage access. Cost is driven mainly by local labor, foundation and soil conditions, the roof and exterior finish, and the four baths and kitchen.
Can I change this plan by chat?
Yes. You can ask to add or remove rooms, move the garage to the other side, or fit a narrower or wider lot. The layout is revised and the room sizes are updated to match.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the plan and sharing it with your builder or lender. The DXF opens in most CAD programs for drafting and edits, and the IFC imports into BIM software for coordination with engineers and trades.
