This single-story plan has 1,020 sq ft of living space, not counting the garage, on a footprint of 33'-6" × 39'-4". A front porch leads into a 6'-8" × 4'-9" foyer. The living room, at 11'-3" × 18'-10", is the largest room. The dining area (11'-11" × 6'-8") and kitchen (11'-11" × 8'-6") sit beside it, so cooking, eating and sitting share one open zone.
A 12'-1" × 5'-2" hall links the living area to the sleeping side. Bedroom 2 measures 11'-11" × 8'-6". The primary bedroom measures 10'-4" × 12'-7" and has a 5'-6" × 5'-5" walk-in closet. The full bath (6'-8" × 6'-2") serves the bedrooms. A 6'-8" × 3'-7" powder room handles guests, and the 5'-6" × 6'-10" laundry stays close to the daily routes. The 1-car garage (14'-11" × 12'-7") is attached.
Layout highlights
- Open kitchen, dining and living zone, with an 11'-3" × 18'-10" living room
- Primary bedroom of 10'-4" × 12'-7" with a 5'-6" × 5'-5" walk-in closet
- Bedroom 2 measures 11'-11" × 8'-6", beside the 6'-8" × 6'-2" full bath
- Separate 6'-8" × 3'-7" powder room keeps guests out of the bedroom hall
- Attached 14'-11" × 12'-7" garage and a 5'-6" × 6'-10" laundry room
Room sizes
| Room | Size | Area |
|---|---|---|
| Foyer | 6'-8" × 4'-9" | 32 sq ft |
| Full Bath | 6'-8" × 6'-2" | 41 sq ft |
| Powder Room | 6'-8" × 3'-7" | 24 sq ft |
| Living Room | 11'-3" × 18'-10" | 213 sq ft |
| Hall | 12'-1" × 5'-2" | 63 sq ft |
| Dining | 11'-11" × 6'-8" | 80 sq ft |
| Kitchen | 11'-11" × 8'-6" | 101 sq ft |
| Bedroom 2 | 11'-11" × 8'-6" | 101 sq ft |
| Primary Bedroom | 10'-4" × 12'-7" | 130 sq ft |
| Laundry | 5'-6" × 6'-10" | 38 sq ft |
| Walk-in Closet | 5'-6" × 5'-5" | 30 sq ft |
| 1-Car Garage | 14'-11" × 12'-7" | 188 sq ft |
Who this plan suits
This plan suits a small household, a first-time buyer or a downsizer who wants one level, two bedrooms and a half bath for guests. It needs a lot at least 33'-6" wide for the house itself, plus side setbacks and a driveway to the garage.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 2 bedrooms, 1.5 baths, open kitchen and living, dining, powder room, laundry, attached 1-car garage, front porch, about 1,100 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a 2 bedroom 1.5 bath house plan?
It is a home with two bedrooms, one full bathroom and one half bathroom, usually a toilet and sink only. In this plan the full bath serves the bedrooms and the powder room serves guests. The layout has 1,020 sq ft of living space on one level.
What affects the cost and lot needs of this plan?
The footprint is 33'-6" × 39'-4", so the lot must fit that plus setbacks and a driveway to the garage. Cost depends on your region, foundation type, finishes and site work. The compact single-story shape keeps the roof and foundation simple, but get local builder quotes.
Can I change this plan by chat?
Yes. You can ask in chat to resize rooms, move the garage to the other side or fit a narrower or wider lot. The plan is then regenerated with updated dimensions, and you can review each change before you download the files.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing and sharing the drawings, and for printing. The DXF opens in CAD programs for editing the 2D linework. The IFC is a BIM model that imports into tools such as Revit or ArchiCAD. Have a local architect or engineer check the plan against your building code before construction.
