This single-story plan measures 64'-4" × 44'-3" and holds 2,130 sq ft of living space, not counting the covered carport. Four bedrooms and three baths are arranged around a central patio. An entry porch leads to a 9'-5" × 7'-3" foyer, and the two-car carport, 21'-0" × 14'-11", sits at the front of the house.
The kitchen, dining area and living room face the patio. The living room is 18'-2" × 18'-0", the dining area is 18'-2" × 8'-8", and the kitchen is 8'-8" × 19'-2". A 5'-5" × 27'-0" bedroom hall serves the sleeping wing, where bedrooms 2, 3 and 4 each run about 10'-4" deep. The primary bedroom is 17'-6" × 10'-1" with an 8'-0" × 5'-10" walk-in closet and a 6'-4" × 10'-4" ensuite. An 8'-8" × 7'-6" utility room completes the plan.
Layout highlights
- Living room of 18'-2" × 18'-0" opens onto the central patio.
- Kitchen at 8'-8" × 19'-2" runs alongside the 18'-2" × 8'-8" dining area.
- Primary suite: 17'-6" × 10'-1" bedroom, 8'-0" × 5'-10" walk-in closet, ensuite.
- Bedrooms 2, 3 and 4 measure 11'-9", 11'-11" and 10'-9" wide, 10'-4" deep.
- Covered carport for two cars, 21'-0" × 14'-11", at the front of the plan.
Room sizes
| Room | Size | Area |
|---|---|---|
| Bedroom 3 | 11'-11" × 10'-4" | 123 sq ft |
| Bedroom 2 | 11'-9" × 10'-4" | 121 sq ft |
| Bath 1 | 5'-1" × 10'-4" | 52 sq ft |
| Hall | 30'-4" × 3'-5" | 103 sq ft |
| Foyer | 9'-5" × 7'-3" | 68 sq ft |
| Covered Carport (2 cars) | 21'-0" × 14'-11" | 313 sq ft |
| Walk-in Closet | 8'-0" × 5'-10" | 47 sq ft |
| Bath 2 | 9'-1" × 5'-10" | 53 sq ft |
| Primary Bedroom | 17'-6" × 10'-1" | 177 sq ft |
| Primary Ensuite | 6'-4" × 10'-4" | 66 sq ft |
| Bedroom 4 | 10'-9" × 10'-4" | 111 sq ft |
| Bedroom Hall | 5'-5" × 27'-0" | 145 sq ft |
| Living Room | 18'-2" × 18'-0" | 327 sq ft |
| Dining | 18'-2" × 8'-8" | 157 sq ft |
| Utility Room | 8'-8" × 7'-6" | 65 sq ft |
| Kitchen | 8'-8" × 19'-2" | 166 sq ft |
Who this plan suits
This plan suits households that want a one-level home with private outdoor space and bedrooms grouped away from the living areas. It needs a lot that fits the 64'-4" × 44'-3" footprint plus the front carport and setbacks.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 4 bedrooms, 3 baths, rooms wrapped around a square inner courtyard (patio), open kitchen, dining and living facing the patio, utility room, covered carport for 2 cars at the front, about 200 m² (2,153 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
