This single-storey plan fits five bedrooms and three bathrooms into 2,810 sq ft of living space, not counting the double garage. The footprint is 70'-10" × 49'-3" with no basement, and the rooms are compact. A 16'-2" × 5'-1" foyer leads to the theatre room (16'-2" × 11'-7") and the main living areas.
The kitchen (14'-4" × 13'-11") connects to a butler's pantry (5'-6" × 14'-8") and a meals area (11'-11" × 13'-11"). The 22'-1" × 14'-8" family room and the alfresco sit beside them. A mudroom (11'-5" × 6'-4") and laundry (11'-5" × 7'-2") serve the double garage (21'-2" × 17'-2"). Bedrooms 3, 4 and 5 and the guest bedroom open off a 41'-11" bedroom hall. The master bedroom (21'-2" × 11'-5") has a 10'-1" × 7'-10" walk-in robe and a 10'-0" × 12'-1" ensuite.
Layout highlights
- Master bedroom 21'-2" × 11'-5" with a 10'-1" × 7'-10" walk-in robe and ensuite.
- Guest bedroom 11'-1" × 12'-3" has its own 10'-0" × 5'-5" ensuite.
- Kitchen 14'-4" × 13'-11" pairs with a 5'-6" × 14'-8" butler's pantry.
- Family room 22'-1" × 14'-8" sits beside the meals area and alfresco.
- Mudroom and laundry link the 21'-2" × 17'-2" double garage to the house.
Room sizes
| Room | Size | Area |
|---|---|---|
| Meals | 11'-11" × 13'-11" | 166 sq ft |
| Kitchen | 14'-4" × 13'-11" | 200 sq ft |
| Mudroom | 11'-5" × 6'-4" | 73 sq ft |
| Laundry | 11'-5" × 7'-2" | 82 sq ft |
| Family Room | 22'-1" × 14'-8" | 325 sq ft |
| Butler's Pantry | 5'-6" × 14'-8" | 81 sq ft |
| Walk-in Robe | 10'-1" × 7'-10" | 79 sq ft |
| Main Bathroom | 10'-1" × 6'-6" | 66 sq ft |
| Double Garage | 21'-2" × 17'-2" | 363 sq ft |
| Master Bedroom | 21'-2" × 11'-5" | 241 sq ft |
| Foyer | 16'-2" × 5'-1" | 82 sq ft |
| Theatre Room | 16'-2" × 11'-7" | 188 sq ft |
| Bedroom Hall | 41'-11" × 5'-2" | 217 sq ft |
| Bedroom 3 | 9'-1" × 12'-3" | 112 sq ft |
| Bedroom 4 | 10'-5" × 12'-3" | 128 sq ft |
| Bedroom 5 | 10'-1" × 12'-3" | 124 sq ft |
| Guest Bedroom | 11'-1" × 12'-3" | 136 sq ft |
| Master Ensuite | 10'-0" × 12'-1" | 120 sq ft |
| Guest Ensuite | 10'-0" × 5'-5" | 54 sq ft |
Who this plan suits
This plan suits families who want five bedrooms, a separate theatre room and a guest suite on one level. It needs a lot that can take a 70'-10" × 49'-3" footprint plus setbacks, with level or gently sloping ground and no basement.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 5 bedrooms, 3 baths, master suite with walk-in robe and ensuite, guest bedroom with ensuite, theatre room, open kitchen with butler's pantry, family and meals, alfresco, laundry, attached 2-car garage, about 260 m² (2,799 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
