This single-story plan provides 2,890 square feet of living space, not counting the garage, on a footprint of 59'-1" × 58'-5". It has five bedrooms, three full baths and a powder room, arranged in a split layout that separates the primary suite from the other four bedrooms. A front porch leads into the main living area.
The kitchen (14'-11" × 16'-4") has an island and opens to the family room (17'-8" × 29'-4") and the dining space (21'-5" × 10'-4"). A pantry, a laundry room (9'-5" × 8'-2") and a mudroom sit between the kitchen and the two-car garage (24'-3" × 15'-3"). The primary bedroom (16'-2" × 16'-4") connects through a short wing hall to its bath and walk-in closet. Bedrooms 2 to 5 share a second hall, with the hall bath and Bath 3 close by.
Layout highlights
- Family room measures 17'-8" × 29'-4" and opens directly to the kitchen and dining.
- Kitchen island room is 14'-11" × 16'-4", with a 9'-5" × 4'-10" pantry beside it.
- Primary bedroom is 16'-2" × 16'-4", with a 13'-11" × 7'-8" bath and walk-in closet.
- Four secondary bedrooms range from 13'-5" × 10'-4" to 14'-3" × 11'-1" off a shared hall.
- Mudroom (5'-1" × 13'-5") and laundry (9'-5" × 8'-2") connect the garage to the kitchen.
Room sizes
| Room | Size | Area |
|---|---|---|
| 2-Car Garage | 24'-3" × 15'-3" | 370 sq ft |
| Mudroom | 5'-1" × 13'-5" | 68 sq ft |
| Laundry | 9'-5" × 8'-2" | 77 sq ft |
| Pantry | 9'-5" × 4'-10" | 46 sq ft |
| Kitchen with Island | 14'-11" × 16'-4" | 243 sq ft |
| Family Room | 17'-8" × 29'-4" | 518 sq ft |
| Primary Bath | 13'-11" × 7'-8" | 107 sq ft |
| Walk-in Closet | 8'-8" × 7'-8" | 66 sq ft |
| Primary Wing Hall | 6'-4" × 11'-5" | 73 sq ft |
| Powder Room | 7'-2" × 4'-6" | 32 sq ft |
| Primary Bedroom | 16'-2" × 16'-4" | 265 sq ft |
| Hall Bath | 9'-1" × 7'-2" | 65 sq ft |
| Bedroom Wing Hall | 9'-1" × 13'-5" | 122 sq ft |
| Bedroom 5 | 14'-3" × 11'-1" | 158 sq ft |
| Bedroom 2 | 14'-3" × 9'-5" | 135 sq ft |
| Dining | 21'-5" × 10'-4" | 221 sq ft |
| Bedroom 4 | 15'-0" × 10'-4" | 155 sq ft |
| Bedroom 3 | 13'-5" × 10'-4" | 138 sq ft |
| Bath 3 | 6'-0" × 10'-4" | 62 sq ft |
Who this plan suits
This plan suits families that want five bedrooms on one level, with the primary suite kept apart from the children's or guest rooms. It needs a lot wide enough for a 59'-1" × 58'-5" footprint plus setbacks, with a front-facing garage and porch.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 5 bedrooms, 3 baths, split layout, open kitchen with island, family room, dining, laundry, attached 2-car garage, front porch, about 2,900 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 5 bedroom 3 bath house plans?
They are home designs with five bedrooms and three full bathrooms, often with a powder room added. This plan has five bedrooms, three full baths and a powder room within 2,890 square feet of living space on a single level.
What affects the lot and building cost of this plan?
The footprint is 59'-1" × 58'-5", so the lot must fit that size plus local setbacks. Single-story construction spreads the roof and foundation over a larger area, and costs also depend on your region, finishes and site conditions.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as resizing or adding rooms, moving the garage to another side, or fitting a narrower lot. The layout is then updated to match your request.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing and sharing the plan. The DXF opens in CAD software for drafting and editing, and the IFC imports into BIM tools. A local architect or engineer should review the plan before permits or construction.
