This 10 meter wide house plan puts three bedrooms and two baths on one level, with 1,240 sq ft of living space. The garage is not included in that figure. The footprint is 36'-9" × 43'-0", and there is no basement or stair. The entry (5'-10" × 11'-7") and the attached 1-car garage (15'-3" × 11'-7") share the same width at the front of the house.
The living room (10'-9" × 23'-5") runs the length of the day zone. The kitchen (10'-4" × 9'-5"), dining area (10'-4" × 8'-8") and laundry (10'-4" × 4'-6") share a 10'-4" width and open toward the garden terrace. A short bedroom hall (3'-7" × 15'-8") separates the sleeping rooms. The primary bedroom (12'-11" × 10'-1") has an ensuite (6'-4" × 6'-4") and a closet (5'-5" × 6'-4"). Bedroom 2 and Bedroom 3 share the hall bathroom.
Layout highlights
- Living room of 10'-9" × 23'-5" runs the full depth of the day zone.
- Kitchen (10'-4" × 9'-5") and dining (10'-4" × 8'-8") are open to the living room.
- Primary suite combines a 12'-11" × 10'-1" bedroom, 6'-4" × 6'-4" ensuite and closet.
- Bedroom 2 (12'-11" × 7'-8") and Bedroom 3 (9'-0" × 10'-1") share a 9'-0" × 5'-2" bathroom.
- Attached 1-car garage of 15'-3" × 11'-7" sits beside the entry, with a separate laundry.
Room sizes
| Room | Size | Area |
|---|---|---|
| Bedroom 2 | 12'-11" × 7'-8" | 99 sq ft |
| Bedroom 3 | 9'-0" × 10'-1" | 91 sq ft |
| Bathroom | 9'-0" × 5'-2" | 47 sq ft |
| Bedroom Hall | 3'-7" × 15'-8" | 56 sq ft |
| Primary Bedroom | 12'-11" × 10'-1" | 131 sq ft |
| Ensuite | 6'-4" × 6'-4" | 41 sq ft |
| Closet | 5'-5" × 6'-4" | 34 sq ft |
| Entry | 5'-10" × 11'-7" | 68 sq ft |
| Garage | 15'-3" × 11'-7" | 177 sq ft |
| Living | 10'-9" × 23'-5" | 252 sq ft |
| Laundry | 10'-4" × 4'-6" | 47 sq ft |
| Kitchen | 10'-4" × 9'-5" | 97 sq ft |
| Dining | 10'-4" × 8'-8" | 89 sq ft |
Who this plan suits
This plan suits a small household or couple with a child who want single-level living, a garage and a garden terrace. It needs a narrow lot that fits a 36'-9" × 43'-0" footprint plus setbacks, with the garden on the rear or side.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 3 bedrooms, 2 baths, single-story plan, open kitchen, dining and living to the garden, laundry, terrace, attached 1-car garage, about 115 m² (1,238 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement; the building is at most 10 m wide (narrow plot).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 10 meter wide house plans?
They are layouts where the building is no more than 10 meters wide, so they fit narrow urban and suburban plots. Rooms are arranged in a line along the depth of the lot, as in this single-story plan with 1,240 sq ft of living space.
What affects the lot and building cost of this plan?
The 36'-9" × 43'-0" footprint sets the minimum lot size, and the single level means a larger foundation and roof area per square foot than a two-story plan. Local setbacks, soil, finishes and the garage and terrace slabs also drive cost. A local builder should price it.
Can I change this plan by chat?
Yes. You can ask in chat to resize rooms, move the garage to the other side, add or remove a bedroom, or adapt the plan to a different lot width. The layout is regenerated so the rooms stay connected.
How do I use the PDF, DXF and IFC files?
The PDF is for reading and sharing the plan with your builder or permit office. The DXF opens in CAD software for drafting, and the IFC imports into BIM tools such as Revit or ArchiCAD. Check dimensions and local code with a licensed professional before building.
