This 5 bedroom house plan has two levels and 1,980 sq ft of living space, garage excluded, on a footprint of 42'-8" × 29'-2". A porch opens to a 6'-2" × 9'-4" entrance hall. From there, the 12'-7" × 19'-6" living room, the 12'-3" × 10'-1" kitchen and the 12'-3" × 9'-0" dining room form one open main living area.
The guest bedroom (6'-11" × 15'-11"), shower room (5'-9" × 7'-4") and utility room (5'-1" × 7'-4") are also on the ground floor, beside the attached garage. An 8'-2" × 7'-4" stair rises to a 3'-3" × 27'-3" landing. It serves bedrooms 2, 3 and 4, each 12'-7" wide, plus the family bath. The primary suite has a 14'-3" × 10'-5" bedroom, a 7'-8" × 8'-8" ensuite and a 5'-9" × 7'-4" walk-in closet.
Layout highlights
- Living room of 12'-7" × 19'-6" shares the ground floor with kitchen and dining.
- Kitchen at 12'-3" × 10'-1" sits beside a 12'-3" × 9'-0" dining room.
- Ground-floor guest bedroom of 6'-11" × 15'-11" pairs with a 5'-9" × 7'-4" shower room.
- Primary suite combines a 14'-3" × 10'-5" bedroom, ensuite and 5'-9" × 7'-4" walk-in closet.
- Three upstairs bedrooms, each 12'-7" wide, open off a 27'-3" landing near the family bath.
Room sizes
| Room | Level | Size | Area |
|---|---|---|---|
| Stair | 1 | 8'-2" × 7'-4" | 60 sq ft |
| Dining | 1 | 12'-3" × 9'-0" | 110 sq ft |
| Kitchen | 1 | 12'-3" × 10'-1" | 124 sq ft |
| Living Room | 1 | 12'-7" × 19'-6" | 246 sq ft |
| Entrance Hall | 1 | 6'-2" × 9'-4" | 57 sq ft |
| Guest Bedroom | 1 | 6'-11" × 15'-11" | 109 sq ft |
| Hall | 1 | 14'-3" × 3'-3" | 46 sq ft |
| Utility Room | 1 | 5'-1" × 7'-4" | 37 sq ft |
| Garage | 1 | 20'-7" × 7'-4" | 151 sq ft |
| Shower Room | 1 | 5'-9" × 7'-4" | 42 sq ft |
| Bedroom 3 | 2 | 12'-7" × 8'-8" | 109 sq ft |
| Bedroom 4 | 2 | 12'-7" × 8'-10" | 111 sq ft |
| Bedroom 2 | 2 | 12'-7" × 9'-0" | 113 sq ft |
| Landing | 2 | 3'-3" × 27'-3" | 88 sq ft |
| Family Bath | 2 | 6'-2" × 8'-8" | 53 sq ft |
| Primary Ensuite | 2 | 7'-8" × 8'-8" | 66 sq ft |
| Primary Bedroom | 2 | 14'-3" × 10'-5" | 149 sq ft |
| Stair | 2 | 8'-2" × 7'-4" | 60 sq ft |
| Walk-in Closet | 2 | 5'-9" × 7'-4" | 42 sq ft |
Who this plan suits
This plan suits families that want a bedroom and shower room on the entry level for guests or relatives, with the remaining bedrooms upstairs. It needs a lot that fits the 42'-8" × 29'-2" footprint plus setbacks, with no basement excavation.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Two-story house, 5 bedrooms, 3 baths, ground floor guest bedroom, shower room, open kitchen, dining, living, utility room; upstairs primary suite, 3 bedrooms and family bath, attached 1-car garage, about 185 m² (1,991 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a 5 bedroom house plan 185 m2?
It is a home design with five bedrooms and about 185 m2 of living area. This version measures 1,980 sq ft of living space across two levels, not counting the garage. It has three bathrooms: a shower room downstairs, a family bath and a primary ensuite upstairs.
What affects the cost and lot requirements of this plan?
The compact 42'-8" × 29'-2" footprint keeps the foundation and roof area modest, and the plan has no basement. Costs mainly depend on your local labor, finishes, site conditions and the attached garage. The lot needs room for the footprint, the porch, driveway access to the garage and local setbacks.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as moving the garage to the other side, adjusting room sizes, swapping a bedroom for an office or fitting a narrower or wider lot. The layout is regenerated so the rooms still connect, and you can review the result before downloading.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the plans, sharing them and discussing them with a builder or designer. The DXF opens in CAD software for editing and drafting. The IFC loads into BIM tools so you can inspect the model in 3D. Local codes and structural requirements still need to be checked by a licensed professional before building.
