This single-story barndominium plan has 2,860 square feet of living space, not counting the garage, inside an 84'-4" × 46'-7" rectangular footprint. Five bedrooms and three baths are arranged around a central living zone. The entry foyer (7'-2" × 11'-7") leads toward the great room, which measures 25'-10" × 22'-9" and sits next to the 15'-0" × 11'-7" dining area.
The kitchen (10'-11" × 21'-5", with an island) connects to a 9'-8" × 5'-9" walk-in pantry. The mudroom (9'-8" × 8'-2") and laundry (9'-8" × 6'-10") link the kitchen to the 29'-4" × 22'-9" garage/shop, so gear and groceries stay out of the main rooms. A 5'-2" × 16'-0" hall leads to the primary suite: a 17'-2" × 11'-7" bedroom, an 8'-0" × 11'-7" bath and a 12'-1" × 6'-2" walk-in closet. A 26'-5" hall serves the other bedrooms, and a covered porch extends the living space outdoors.
Layout highlights
- Great room at 25'-10" × 22'-9" anchors the plan next to the dining area.
- Kitchen island room (10'-11" × 21'-5") opens to a 9'-8" × 5'-9" walk-in pantry.
- Mudroom (9'-8" × 8'-2") and laundry (9'-8" × 6'-10") sit between kitchen and garage.
- Primary suite includes a 12'-1" × 6'-2" walk-in closet and an 8'-0" × 11'-7" bath.
- Garage/shop measures 29'-4" × 22'-9" within an 84'-4" × 46'-7" footprint.
Room sizes
| Room | Size | Area |
|---|---|---|
| Walk-in Pantry | 9'-8" × 5'-9" | 55 sq ft |
| Laundry | 9'-8" × 6'-10" | 66 sq ft |
| Mudroom | 9'-8" × 8'-2" | 78 sq ft |
| Kitchen with Island | 10'-11" × 21'-5" | 235 sq ft |
| Dining | 15'-0" × 11'-7" | 175 sq ft |
| Entry Foyer | 7'-2" × 11'-7" | 83 sq ft |
| Bedroom 5 | 10'-5" × 11'-7" | 121 sq ft |
| Garage / Shop | 29'-4" × 22'-9" | 668 sq ft |
| Great Room | 25'-10" × 22'-9" | 589 sq ft |
| Primary Bedroom | 17'-2" × 11'-7" | 200 sq ft |
| Primary Bath | 8'-0" × 11'-7" | 93 sq ft |
| Primary Wing Hall | 5'-2" × 16'-0" | 83 sq ft |
| Primary Walk-in Closet | 12'-1" × 6'-2" | 74 sq ft |
| Bath 3 | 5'-10" × 9'-5" | 55 sq ft |
| Bath 2 | 5'-10" × 9'-5" | 55 sq ft |
| Bedroom 3 | 8'-4" × 16'-0" | 133 sq ft |
| Bedroom Wing Hall | 26'-5" × 6'-2" | 163 sq ft |
| Bedroom 2 | 13'-1" × 9'-8" | 126 sq ft |
| Bedroom 4 | 12'-11" × 9'-8" | 125 sq ft |
Who this plan suits
This plan suits families or multigenerational households that want five bedrooms on one level, plus a working garage/shop. It needs a lot at least wide enough for the 84'-4" × 46'-7" footprint plus setbacks, and level or gently sloping ground suits a rectangular metal building.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story barndominium, rectangular metal building, 5 bedrooms, 3 baths, primary suite with walk-in closet, open great room, kitchen with island and pantry, laundry, mudroom, attached garage/shop, covered porch, about 2,900 sq ft of living space.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 5 bedroom barndominium floor plans?
They are plans for a barndominium, a living space built in a metal-frame or post-frame building shell, with five bedrooms. This one has 2,860 sq ft of living space on one level, with 3 baths and an attached garage/shop.
What affects the cost and lot requirements for this plan?
The main drivers are the 84'-4" × 46'-7" footprint, foundation type, local wind and snow loads, insulation, and finishes. The lot must fit the footprint plus setbacks, driveway access to the garage/shop, and septic or utility connections where they apply.
Can I change this plan by chat?
Yes. You can ask in chat to resize or rearrange rooms, move the garage to the other side, or fit the plan to a narrower or wider lot. The layout is then updated and the room sizes are recalculated.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the layout and sharing it with builders or lenders. The DXF opens in most CAD programs for drafting and editing, and the IFC imports into BIM software. Local permits usually require review and stamping by a licensed professional.
