This single-story plan has 1,080 sq ft of living space, not counting the carport, on a footprint of 34'-5" × 40'-4". It has no steps and no basement. The entry (9'-8" × 4'-6") opens to a 1.2 m wide hall (16'-8" × 4'-6") that connects the bedrooms, baths and storage.
The kitchen (9'-4" × 10'-8"), dining area (10'-4" × 8'-8") and living room (16'-2" × 12'-7") make up one open social zone, and the plan includes a terrace. The primary bedroom measures 10'-8" × 10'-8" and the second bedroom 9'-4" × 11'-5". The accessible bath (6'-6" × 10'-8") has a walk-in shower. A second bath (6'-2" × 7'-2"), a utility room (6'-2" × 5'-10") and a storage room (5'-5" × 4'-6") complete the plan. A covered carport (14'-7" × 10'-8") sits at the front.
Layout highlights
- Single level with no steps and no basement, on a 34'-5" × 40'-4" footprint.
- Hall is 1.2 m wide and 16'-8" long, linking the bedrooms, baths and storage.
- Accessible bath is 6'-6" × 10'-8" and includes a walk-in shower.
- Open living room (16'-2" × 12'-7"), dining (10'-4" × 8'-8") and kitchen (9'-4" × 10'-8").
- Covered carport (14'-7" × 10'-8") at the front, plus a utility room of 6'-2" × 5'-10".
Room sizes
| Room | Size | Area |
|---|---|---|
| Kitchen | 9'-4" × 10'-8" | 99 sq ft |
| Bedroom 2 | 9'-4" × 11'-5" | 106 sq ft |
| Dining | 10'-4" × 8'-8" | 89 sq ft |
| Utility Room | 6'-2" × 5'-10" | 36 sq ft |
| Bath | 6'-2" × 7'-2" | 44 sq ft |
| Living | 16'-2" × 12'-7" | 204 sq ft |
| Storage | 5'-5" × 4'-6" | 24 sq ft |
| Hall (1.2 m wide) | 16'-8" × 4'-6" | 75 sq ft |
| Entry | 9'-8" × 4'-6" | 44 sq ft |
| Primary Bedroom | 10'-8" × 10'-8" | 113 sq ft |
| Accessible Bath | 6'-6" × 10'-8" | 69 sq ft |
| Covered Carport | 14'-7" × 10'-8" | 155 sq ft |
Who this plan suits
This plan suits wheelchair users, older owners planning to age in place, and households that want compact single-level living with two bedrooms. It needs a fairly level lot wide enough for a 34'-5" building width, plus room for the front carport and the terrace.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 2 bedrooms, 2 baths, fully step-free, 1.2 m wide hall, wheelchair-accessible bath with walk-in shower, open kitchen, dining and living, utility room, terrace, covered carport for 1 car at the front, about 100 m² (1,076 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are barrier free bungalow plans?
Barrier free bungalow plans describe single-story homes laid out so that every room can be reached without steps. They use wider halls, level thresholds and bathrooms with room to move. This plan has a 1.2 m hall and an accessible bath of 6'-6" × 10'-8" with a walk-in shower.
What affects the cost and lot requirements for this plan?
The footprint is 34'-5" × 40'-4" for 1,080 sq ft of living space, and the carport is additional. Site grading matters most, because a level entry from the carport and terrace depends on how the lot slopes. Local codes, foundation type, finishes and the accessibility fittings you choose will also change the final cost.
Can I change this plan by chat?
Yes. You can ask for changes in chat, such as resizing rooms, moving the carport to the other side or adjusting the plan for a narrower or wider lot. The layout is then regenerated so the rooms and the 1.2 m hall still connect.
How do I use the PDF, DXF and IFC files?
The PDF is for reading and sharing the plan with family, builders or a permit office. The DXF opens in CAD programs for 2D drafting and edits. The IFC is a BIM model you can open in compatible software to check the 3D geometry, and a local professional should review all files before construction.
