This single-story plan measures 63'-4" × 44'-0" and has 2,260 square feet of living space, not counting the garage. A front porch opens to a 12'-3" × 5'-5" foyer. The 29'-8" × 13'-9" great room, the 21'-7" × 8'-2" kitchen with a 7'-6" × 5'-2" pantry, and the 9'-9" × 13'-7" dining room make up the main living area. A 12'-3" × 7'-0" study and an 8'-0" × 3'-5" powder room complete the public side of the house.
The 16'-6" × 23'-1" garage enters through a 9'-9" × 5'-1" mudroom beside an 11'-5" × 5'-1" laundry. A 36'-0" × 4'-2" bedroom hall serves the secondary bedrooms. Bedrooms 2 and 4, each 12'-9" × 9'-4", share a 5'-10" × 9'-4" Jack and Jill bath. Bedroom 3 is 11'-11" × 9'-4". The primary suite is a separate wing, with a 16'-6" × 12'-1" bedroom, a 16'-6" × 6'-0" bath and a 7'-6" × 8'-2" walk-in closet.
Layout highlights
- Jack and Jill bath, 5'-10" × 9'-4", sits between Bedrooms 2 and 4.
- Bedrooms 2 and 4 are each 12'-9" × 9'-4"; Bedroom 3 is 11'-11" × 9'-4".
- Primary suite pairs a 16'-6" × 12'-1" bedroom with a 16'-6" × 6'-0" bath.
- Great room, 29'-8" × 13'-9", sits beside a 21'-7" × 8'-2" kitchen and pantry.
- Garage entry passes a 9'-9" × 5'-1" mudroom and an 11'-5" × 5'-1" laundry.
Room sizes
| Room | Size | Area |
|---|---|---|
| Primary Bath | 16'-6" × 6'-0" | 100 sq ft |
| Primary Bedroom | 16'-6" × 12'-1" | 200 sq ft |
| 2-Car Garage | 16'-6" × 23'-1" | 382 sq ft |
| Bedroom 4 | 12'-9" × 9'-4" | 119 sq ft |
| Bedroom 2 | 12'-9" × 9'-4" | 119 sq ft |
| Jack and Jill Bath | 5'-10" × 9'-4" | 54 sq ft |
| Bedroom 3 | 11'-11" × 9'-4" | 111 sq ft |
| Bedroom Hall | 36'-0" × 4'-2" | 151 sq ft |
| Powder Room | 8'-0" × 3'-5" | 27 sq ft |
| Walk-in Closet | 7'-6" × 8'-2" | 61 sq ft |
| Pantry | 7'-6" × 5'-2" | 39 sq ft |
| Great Room | 29'-8" × 13'-9" | 407 sq ft |
| Kitchen | 21'-7" × 8'-2" | 176 sq ft |
| Mudroom | 9'-9" × 5'-1" | 49 sq ft |
| Laundry | 11'-5" × 5'-1" | 58 sq ft |
| Dining | 9'-9" × 13'-7" | 133 sq ft |
| Foyer | 12'-3" × 5'-5" | 66 sq ft |
| Study | 12'-3" × 7'-0" | 86 sq ft |
Who this plan suits
This plan suits families who want two children's bedrooms to share a bath while the parents keep a private primary suite. It needs a lot that fits the 63'-4" × 44'-0" footprint plus setbacks, with the front porch and garage facing the street.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 4 bedrooms, 2.5 baths, two bedrooms sharing a Jack and Jill bathroom, separate primary suite, open kitchen, great room, laundry, attached 2-car garage, front porch, about 2,250 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
