This single-story plan fits three bedrooms and one bathroom into 1,050 sq ft of living space, not counting the carport. The footprint measures 41'-4" × 32'-2" and there is no basement. A covered carport sits at the front of the house, and the entry (5'-1" × 6'-8") opens toward the main living area.
The kitchen (13'-3" × 7'-4"), dining area (13'-3" × 8'-4") and living room (11'-9" × 16'-1") form one open zone, so cooking, meals and seating stay in view of each other. The laundry (3'-11" × 6'-8") is a separate small room, and the covered terrace extends the living space outdoors. A narrow bedroom hall (3'-7" × 17'-8") serves the sleeping wing: bedroom 1 at 9'-8" × 10'-11", bedroom 3 at 9'-8" × 9'-5", bedroom 2 at 9'-8" × 9'-0", and the shared bathroom at 8'-0" × 5'-1".
Layout highlights
- Open kitchen, dining and living zone: 13'-3" wide kitchen and dining, 11'-9" × 16'-1" living room.
- Three bedrooms of 9'-8" width, with bedroom 1 the largest at 9'-8" × 10'-11".
- Bedroom hall of 3'-7" × 17'-8" connects all three bedrooms and the bathroom.
- Separate laundry room of 3'-11" × 6'-8" and a defined entry of 5'-1" × 6'-8".
- Compact 41'-4" × 32'-2" footprint with a covered terrace and a front carport.
Room sizes
| Room | Size | Area |
|---|---|---|
| Laundry | 3'-11" × 6'-8" | 26 sq ft |
| Entry | 5'-1" × 6'-8" | 34 sq ft |
| Kitchen | 13'-3" × 7'-4" | 97 sq ft |
| Dining | 13'-3" × 8'-4" | 110 sq ft |
| Living | 11'-9" × 16'-1" | 189 sq ft |
| Bedroom Hall | 3'-7" × 17'-8" | 63 sq ft |
| Bathroom | 8'-0" × 5'-1" | 40 sq ft |
| Bedroom 1 | 9'-8" × 10'-11" | 106 sq ft |
| Bedroom 3 | 9'-8" × 9'-5" | 91 sq ft |
| Bedroom 2 | 9'-8" × 9'-0" | 87 sq ft |
Who this plan suits
This plan suits small families or couples who want three bedrooms and a shared living space on one level without a basement. It needs a lot wide enough for a 41'-4" × 32'-2" footprint plus room for the front carport and the terrace.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 3 bedrooms, 1 bath, compact plan, kitchen open to dining and living, laundry, covered terrace, covered carport for 1 car at the front, about 95 m² (1,023 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a 3 bedroom house plan of 95 m2?
It is a compact single-story home with three bedrooms, sized around 95 m2 of living space. This version measures 1,050 sq ft of living area with one bathroom, and the carport is not counted in that figure.
What affects the lot and building cost of this plan?
The 41'-4" × 32'-2" footprint sets the minimum lot width and depth, and the carport and terrace add roof area beyond the living space. Costs depend mostly on your local labor, materials, foundation type and finish level, so get a local estimate before you commit.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as resizing rooms, moving the carport to another side, or adapting the layout to a narrower lot. The plan is then regenerated with the updated room sizes.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the layout and sharing it with builders or permit offices. The DXF opens in CAD software for 2D editing, and the IFC imports into BIM tools for 3D coordination. Have a local professional check the plans against your site and building codes before construction.
