This single-story ranch plan has 2,980 square feet of living space, not counting the garage, on a footprint of 73'-10" × 50'-10". A front porch opens to an 8'-10" × 10'-4" foyer. Beyond it, the 21'-11" × 24'-5" family room joins the 10'-1" × 24'-1" kitchen with island. A 9'-0" × 7'-2" pantry and a 9'-0" × 16'-6" dining room sit alongside.
The bedrooms are split. The primary suite has its own wing off a 15'-0" × 5'-10" hall. It includes a 14'-3" × 17'-10" bedroom, a 9'-5" × 15'-0" bath and a 9'-5" × 8'-8" walk-in closet. Four more bedrooms line a 4'-1" × 37'-6" hall, served by a hall bath and a shared bath. The mudroom (6'-4" × 11'-7") and laundry (6'-4" × 12'-5") handle the entry from the 24'-10" × 24'-5" three-car garage.
Layout highlights
- Primary suite in a separate wing with a 9'-5" × 8'-8" walk-in closet and 9'-5" × 15'-0" bath.
- Kitchen with island measures 10'-1" × 24'-1" and has a 9'-0" × 7'-2" pantry.
- Family room at 21'-11" × 24'-5" sits beside the kitchen and a 9'-0" × 16'-6" dining room.
- Four secondary bedrooms along a 37'-6" hall, each between 9'-8" and 12'-3" in width or depth.
- Mudroom and laundry, both 6'-4" wide, connect to a 24'-10" × 24'-5" three-car garage.
Room sizes
| Room | Size | Area |
|---|---|---|
| Dining | 9'-0" × 16'-6" | 149 sq ft |
| Pantry | 9'-0" × 7'-2" | 64 sq ft |
| Kitchen with Island | 10'-1" × 24'-1" | 243 sq ft |
| Walk-in Closet | 9'-5" × 8'-8" | 82 sq ft |
| Primary Bath | 9'-5" × 15'-0" | 142 sq ft |
| Primary Bedroom | 14'-3" × 17'-10" | 254 sq ft |
| Primary Wing Hall | 15'-0" × 5'-10" | 88 sq ft |
| Foyer | 8'-10" × 10'-4" | 91 sq ft |
| Laundry | 6'-4" × 12'-5" | 79 sq ft |
| Mudroom | 6'-4" × 11'-7" | 74 sq ft |
| 3-Car Garage | 24'-10" × 24'-5" | 607 sq ft |
| Family Room | 21'-11" × 24'-5" | 535 sq ft |
| Bedroom Hall | 4'-1" × 37'-6" | 153 sq ft |
| Bedroom 3 | 12'-3" × 9'-8" | 118 sq ft |
| Bedroom 2 | 12'-3" × 10'-5" | 128 sq ft |
| Hall Bath | 12'-3" × 5'-10" | 72 sq ft |
| Bedroom 5 | 12'-3" × 10'-5" | 128 sq ft |
| Bedroom 4 | 11'-9" × 10'-11" | 129 sq ft |
| Shared Bath | 5'-5" × 10'-11" | 59 sq ft |
Who this plan suits
This plan suits larger households that want five bedrooms on one level, with the primary suite set apart from the other bedrooms. It needs a wide lot: the footprint is 73'-10" × 50'-10", so check setbacks before choosing it.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story ranch house, 5 bedrooms, 3 baths, split bedroom layout, open kitchen with island and pantry, family room, dining, laundry, mudroom, attached 3-car garage, front porch, about 3,000 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
