This plan fits 790 sq ft of living space on a single level with a footprint of 35'-5" × 24'-3". There is no garage, so the whole footprint goes to rooms and the front porch. The living room measures 17'-6" × 11'-10" and opens to the kitchen at 10'-11" × 9'-4", which gives you one shared space for cooking, dining and sitting.
A 4'-10" × 10'-1" hall links that shared space to the private rooms. Bedroom 1 is 10'-4" × 12'-3" and Bedroom 2 is 10'-4" × 9'-8". The bathroom (4'-10" × 8'-4") and the laundry closet (4'-10" × 3'-1") share the hall's 4'-10" width, so the service rooms line up in one compact strip. Both bedrooms are reached from the hall, away from the cooking and seating area, and the front porch marks the entry.
Layout highlights
- Open kitchen (10'-11" × 9'-4") flows into a 17'-6" × 11'-10" living room.
- Bedroom 1 is 10'-4" × 12'-3"; Bedroom 2 is 10'-4" × 9'-8".
- One 4'-10" × 8'-4" bathroom opens off the 4'-10" × 10'-1" hall.
- Laundry closet at 4'-10" × 3'-1" sits beside the bathroom, not in a bedroom.
- Compact 35'-5" × 24'-3" footprint with a front porch and no garage.
Room sizes
| Room | Size | Area |
|---|---|---|
| Kitchen | 10'-11" × 9'-4" | 102 sq ft |
| Living Room | 17'-6" × 11'-10" | 207 sq ft |
| Bathroom | 4'-10" × 8'-4" | 40 sq ft |
| Hall | 4'-10" × 10'-1" | 49 sq ft |
| Laundry Closet | 4'-10" × 3'-1" | 15 sq ft |
| Bedroom 1 | 10'-4" × 12'-3" | 126 sq ft |
| Bedroom 2 | 10'-4" × 9'-8" | 99 sq ft |
Who this plan suits
This plan suits a couple, a single owner or a small household that wants two bedrooms and one bath without extra circulation space. Its 35'-5" × 24'-3" footprint fits a narrow lot, a backyard cottage site or a rural parcel where a single level is preferred.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Small one-story house with about 800 sq ft of living space: 2 bedrooms, 1 bath, open kitchen and living, laundry closet, front porch.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 800 sq ft house plans?
They are plans for homes with roughly 800 sq ft of living space, usually one or two bedrooms and a shared kitchen and living area. This version has 790 sq ft of living space, 2 bedrooms and 1 bath on one level, and the garage is not counted.
What affects the lot and cost of building this plan?
The footprint is 35'-5" × 24'-3", so you need a lot with room for that rectangle plus setbacks and the front porch. Cost depends on your region, foundation type, finishes and site work, so get local builder quotes using the plan set.
Can I change this plan by chat?
Yes. You can ask in chat to resize or rearrange rooms, add a garage on a chosen side, or adapt the layout to a narrower or wider lot. The plan is regenerated and the room sizes and living area are updated to match.
How do I use the PDF, DXF and IFC files?
The PDF is for review, printing and sharing with a builder or permit office. The DXF opens in CAD software for drafting and measuring, and the IFC imports into BIM tools for modeling. Local codes and structural requirements still need to be checked by a licensed professional.
