This single-story plan provides 1,280 sq ft of living space, not counting the carport, with 3 bedrooms and 2 baths on a footprint of 26'-3" × 65'-7". A covered carport for two cars, 10'-11" × 28'-0", sits at the front, and a 10'-11" × 6'-2" entry leads into the house.
The living and dining room is one 12'-11" × 25'-9" space, with the 8'-0" × 11'-1" kitchen open to it and the 8'-0" × 5'-9" laundry close by. A hall, 10'-1" × 8'-2", links the bedrooms and the shared bathroom. Bedroom 2 measures 10'-11" × 9'-1" and Bedroom 3 measures 10'-4" × 10'-8". The primary bedroom, 13'-7" × 10'-8", has its own 7'-0" × 8'-2" bath. The gourmet balcony at the back extends the living area outdoors.
Layout highlights
- Living and dining room in one 12'-11" × 25'-9" space, open to the kitchen.
- Covered carport for two cars, 10'-11" × 28'-0", at the front of the house.
- Primary bedroom of 13'-7" × 10'-8" with a private 7'-0" × 8'-2" bath.
- Bedrooms 2 and 3 measure 10'-11" × 9'-1" and 10'-4" × 10'-8".
- Separate 8'-0" × 5'-9" laundry and a gourmet balcony at the back.
Room sizes
| Room | Size | Area |
|---|---|---|
| Covered Carport (2 cars) | 10'-11" × 28'-0" | 307 sq ft |
| Entry | 10'-11" × 6'-2" | 68 sq ft |
| Bedroom 2 | 10'-11" × 9'-1" | 100 sq ft |
| Laundry | 8'-0" × 5'-9" | 46 sq ft |
| Kitchen | 8'-0" × 11'-1" | 89 sq ft |
| Living / Dining | 12'-11" × 25'-9" | 332 sq ft |
| Bathroom | 6'-4" × 8'-2" | 52 sq ft |
| Hall | 10'-1" × 8'-2" | 82 sq ft |
| Primary Bath | 7'-0" × 8'-2" | 57 sq ft |
| Bedroom 3 | 10'-4" × 10'-8" | 110 sq ft |
| Primary Bedroom | 13'-7" × 10'-8" | 144 sq ft |
Who this plan suits
This plan suits a family or couple who want three bedrooms and an open living area on one level, with no stairs or basement. It needs a long, narrow lot that can hold a 26'-3" × 65'-7" footprint, with the carport at the street side.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 3 bedrooms, 2 baths, primary suite, kitchen open to dining and living, laundry, gourmet balcony at the back, covered carport for 2 cars at the front, about 120 m² (1,292 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement; for a 10 x 30 m lot, so the building is at most 8.0 m wide (side setbacks) and about 23 m deep.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are house plans for a 10x30 lot?
They are layouts sized for a long, narrow lot, with rooms arranged in a line from the street to the back. This plan uses a 26'-3" × 65'-7" footprint, with the carport and entry at the front and the living space and balcony toward the rear.
What affects the cost of building this plan and the lot it needs?
Cost depends mainly on the 1,280 sq ft of living area, the covered carport, the balcony, local labor and materials, and the foundation your soil requires. Check your local side and front setbacks against the 26'-3" × 65'-7" footprint before you buy or build.
Can I change this plan by chat?
Yes. You can ask for changes in chat, such as resizing or moving rooms, switching the carport to the other side, or adjusting the plan to a narrower or wider lot. The plan is then regenerated with updated room sizes.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing and sharing the layout and dimensions. The DXF opens in CAD software for drafting and edits, and the IFC imports into BIM tools for coordination. Have a local architect or engineer check the plan against your local code before construction.
