This single-story barndominium has 1,430 sq ft of living space, not counting the garage. It fits a simple rectangular footprint of 43'-0" × 50'-2" with a covered porch. The main living area is a 14'-7" × 24'-5" great room open to a kitchen with an island, which measures 19'-3" × 8'-6". A 6'-6" × 5'-2" pantry, a 9'-0" × 5'-2" laundry and a 6'-4" × 8'-6" mudroom handle daily storage and entry, next to the 25'-3" × 19'-10" attached 2-car shop garage.
The sleeping areas are grouped off the great room. A 20'-6" × 3'-3" bedroom hall serves Bedroom 2 (10'-5" × 10'-0"), Bedroom 3 (9'-8" × 10'-0") and a 9'-9" × 5'-2" hall bath. The primary bedroom is 11'-1" × 13'-7" and includes an 8'-8" × 5'-6" walk-in closet and an 8'-8" × 7'-8" primary bath.
Layout highlights
- Great room of 14'-7" × 24'-5" opens to the kitchen and island.
- Kitchen with island measures 19'-3" × 8'-6", with a 6'-6" × 5'-2" pantry.
- Mudroom (6'-4" × 8'-6") and laundry (9'-0" × 5'-2") sit by the garage.
- Primary suite pairs an 8'-8" × 5'-6" walk-in closet with an 8'-8" × 7'-8" bath.
- Attached shop garage is 25'-3" × 19'-10" on a 43'-0" × 50'-2" footprint.
Room sizes
| Room | Size | Area |
|---|---|---|
| Great Room | 14'-7" × 24'-5" | 356 sq ft |
| 2-Car Shop Garage | 25'-3" × 19'-10" | 501 sq ft |
| Kitchen with Island | 19'-3" × 8'-6" | 163 sq ft |
| Mudroom | 6'-4" × 8'-6" | 54 sq ft |
| Hall Bath | 9'-9" × 5'-2" | 51 sq ft |
| Pantry | 6'-6" × 5'-2" | 34 sq ft |
| Laundry | 9'-0" × 5'-2" | 47 sq ft |
| Bedroom Hall | 20'-6" × 3'-3" | 66 sq ft |
| Bedroom 3 | 9'-8" × 10'-0" | 96 sq ft |
| Bedroom 2 | 10'-5" × 10'-0" | 104 sq ft |
| Primary Bedroom | 11'-1" × 13'-7" | 151 sq ft |
| Walk-in Closet | 8'-8" × 5'-6" | 48 sq ft |
| Primary Bath | 8'-8" × 7'-8" | 66 sq ft |
Who this plan suits
This plan suits households who want three bedrooms and two baths on one level, with a shop garage attached to the home. It needs a lot that can hold a 43'-0" × 50'-2" footprint plus setbacks, driveway access to the garage and room for the covered porch.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story barndominium, simple rectangular metal building with about 1,500 sq ft of living space (shop not included): 3 bedrooms, 2 baths, primary suite with walk-in closet, open great room with kitchen island, pantry, laundry, mudroom, attached 2-car shop garage, covered porch.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 1500 sq ft barndominium floor plans?
They are single-story or compact metal-building homes that combine living space with a shop or garage under one simple roof. This version has 1,430 sq ft of living area, excluding the 25'-3" × 19'-10" garage, with 3 bedrooms and 2 baths.
What affects building cost and lot requirements for this plan?
The rectangular 43'-0" × 50'-2" footprint keeps the structure simple, but foundation type, metal building package, insulation, finishes and local labor rates drive the final cost. Your lot must allow the footprint, setbacks, garage access and a suitable site for the covered porch.
Can I change this plan by chat?
Yes. You can ask to resize rooms, move the garage to the other side or adjust the plan for a narrower or wider lot. The layout is updated to match your request, and you can review the revised plan before downloading it.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the plan and sharing it with builders, lenders or your permit office. The DXF opens in most CAD programs for drafting and edits, and the IFC imports into BIM software for coordination. Local code review and engineering are still needed before construction.
