This single-story ranch plan provides 1,450 sq ft of living space, not counting the garage, on a footprint of 40'-8" × 48'-3". A front porch opens to a 6'-4" × 9'-0" foyer. Beyond it, the living room (23'-5" × 11'-3"), the kitchen with island (12'-11" × 10'-9") and the dining area (10'-1" × 10'-9") form one connected living zone.
The 2-car garage (23'-5" × 16'-2") enters through an 8'-8" × 6'-10" mudroom, with a 6'-10" × 6'-10" laundry beside it, so daily traffic stays out of the living areas. The bedrooms sit along a 20'-3" bedroom hall. Bedroom 2 (10'-11" × 9'-4") and Bedroom 3 (10'-11" × 9'-9") share the hall bath (7'-2" × 6'-10"). The primary bedroom (9'-1" × 16'-2") has a 5'-5" × 9'-9" bath and a 5'-5" × 6'-0" walk-in closet.
Layout highlights
- Living room at 23'-5" × 11'-3" runs open to the kitchen and dining area.
- Kitchen with island measures 12'-11" × 10'-9", next to a 10'-1" × 10'-9" dining room.
- Garage entry passes through an 8'-8" × 6'-10" mudroom and a 6'-10" × 6'-10" laundry.
- Bedrooms 2 and 3 are both 10'-11" wide and share a 7'-2" × 6'-10" hall bath.
- Primary suite combines a 9'-1" × 16'-2" bedroom, 5'-5" × 9'-9" bath and 5'-5" × 6'-0" closet.
Room sizes
| Room | Size | Area |
|---|---|---|
| Living Room | 23'-5" × 11'-3" | 264 sq ft |
| Kitchen with Island | 12'-11" × 10'-9" | 139 sq ft |
| Dining | 10'-1" × 10'-9" | 109 sq ft |
| Mudroom | 8'-8" × 6'-10" | 59 sq ft |
| Laundry | 6'-10" × 6'-10" | 47 sq ft |
| Hall Bath | 7'-2" × 6'-10" | 49 sq ft |
| 2-Car Garage | 23'-5" × 16'-2" | 380 sq ft |
| Foyer | 6'-4" × 9'-0" | 57 sq ft |
| Bedroom Hall | 3'-7" × 20'-3" | 72 sq ft |
| Bedroom 2 | 10'-11" × 9'-4" | 102 sq ft |
| Bedroom 3 | 10'-11" × 9'-9" | 107 sq ft |
| Primary Bedroom | 9'-1" × 16'-2" | 148 sq ft |
| Primary Bath | 5'-5" × 9'-9" | 53 sq ft |
| Walk-in Closet | 5'-5" × 6'-0" | 32 sq ft |
Who this plan suits
This plan suits small families, couples who want a guest room or office, and buyers who prefer single-level living with an attached garage. It needs a lot wide enough for a 40'-8" × 48'-3" footprint plus setbacks, with the front porch and garage facing the street.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story ranch house, 3 bedrooms, 2 baths, open kitchen with island, dining, living, laundry, mudroom, attached 2-car garage, front porch, about 1,500 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 1500 sq ft ranch house plans?
They are single-story homes of roughly 1,500 sq ft of living space, with all rooms on one level and no stairs. This version has 1,450 sq ft of living space, three bedrooms and two baths, and the garage is not counted in that figure.
What affects the lot and building cost for this plan?
The 40'-8" × 48'-3" footprint sets the minimum lot width and depth once setbacks are added. A single-story layout spreads the foundation and roof over more area than a two-story home of the same size, so site conditions, foundation type and local labor rates drive cost. Get a local builder's quote for actual figures.
Can I change this plan by chat?
Yes. You can ask for changes such as moving the garage to the other side, resizing or adding rooms, or fitting a narrower or wider lot. The layout is regenerated so the rooms still connect, and you can review the result before you download files.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing and printing the plan and sharing it with a builder or contractor. The DXF opens in CAD software for editing the 2D drawings, and the IFC loads into BIM tools for a 3D model. Have a local engineer or designer check the plans against your site and code requirements before construction.
