This single-story L-shaped bungalow has 2,020 sq ft of living space on a 62'-0" × 42'-8" footprint. The 2-car garage (21'-5" × 16'-2") is not counted in that figure. The foyer (7'-4" × 9'-4") leads to the shared rooms: a 25'-2" × 11'-11" living room, a 10'-8" × 10'-11" dining room and a kitchen with island measuring 9'-0" × 17'-10". A 9'-0" × 5'-10" utility room supports the kitchen, and a covered terrace extends the living area outdoors.
The sleeping rooms are grouped around an 8'-10" × 16'-8" bedroom hall. Bedrooms 2, 3 and 4 measure 7'-4" × 16'-2", 7'-4" × 15'-3" and 8'-10" × 11'-11", with Bathroom 2 (8'-2" × 6'-10") and Bathroom 3 (7'-4" × 8'-6") serving them. The primary suite combines an 11'-1" × 16'-2" bedroom, a 9'-9" × 6'-4" dressing room and a 9'-9" × 9'-5" bath. An 8'-0" × 11'-3" study provides a separate place to work.
Layout highlights
- Living room of 25'-2" × 11'-11" sits beside a 10'-8" × 10'-11" dining room.
- Kitchen with island at 9'-0" × 17'-10", plus a 9'-0" × 5'-10" utility room.
- Primary suite: 11'-1" × 16'-2" bedroom, 9'-9" × 6'-4" dressing room, 9'-9" × 9'-5" bath.
- Three further bedrooms open off an 8'-10" × 16'-8" bedroom hall.
- Attached 2-car garage of 21'-5" × 16'-2", covered terrace and covered entry porch.
Room sizes
| Room | Size | Area |
|---|---|---|
| Kitchen with Island | 9'-0" × 17'-10" | 160 sq ft |
| Utility Room | 9'-0" × 5'-10" | 52 sq ft |
| Dining | 10'-8" × 10'-11" | 116 sq ft |
| Living Room | 25'-2" × 11'-11" | 301 sq ft |
| Foyer | 7'-4" × 9'-4" | 68 sq ft |
| Bathroom 2 | 8'-2" × 6'-10" | 56 sq ft |
| 2-Car Garage | 21'-5" × 16'-2" | 348 sq ft |
| Primary Bath | 9'-9" × 9'-5" | 92 sq ft |
| Dressing Room | 9'-9" × 6'-4" | 62 sq ft |
| Primary Bedroom | 11'-1" × 16'-2" | 180 sq ft |
| Study | 8'-0" × 11'-3" | 90 sq ft |
| Bedroom Hall | 8'-10" × 16'-8" | 147 sq ft |
| Bedroom 4 | 8'-10" × 11'-11" | 105 sq ft |
| Bedroom 3 | 7'-4" × 15'-3" | 112 sq ft |
| Bathroom 3 | 7'-4" × 8'-6" | 62 sq ft |
| Bedroom 2 | 7'-4" × 16'-2" | 119 sq ft |
Who this plan suits
This plan suits families who want four bedrooms, a study and a dressing room on one level with no stairs or basement. It needs a lot that fits the 62'-0" × 42'-8" footprint plus setbacks, with room for the garage and terrace.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 4 bedrooms, 3 baths, L-shaped bungalow, primary suite with dressing room, open kitchen with island, dining, living, study, utility room, covered terrace, attached 2-car garage, about 190 m² (2,045 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 190 square meter house plans?
They describe a home of roughly 190 m² of living space, which is about 2,045 sq ft. This plan measures 2,020 sq ft of living area, excluding the garage. It is a single-story layout with 4 bedrooms and 3 baths.
What affects the lot and building cost of this plan?
The L-shaped 62'-0" × 42'-8" footprint is a single level, so it needs a wider lot than a two-story house of similar size. Foundation, roof area, finishes and local labor rates drive cost more than the room count. Get a local builder's estimate before you commit.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as resizing a bedroom, moving the garage to the other side or fitting a narrower lot. The plan is regenerated with the new layout, and you can keep adjusting it until it fits.
How do I use the PDF, DXF and IFC files?
The PDF is for review, printing and sharing with your builder or permit office. The DXF opens in CAD software for drafting and site layout, and the IFC imports into BIM tools. Local codes and engineering still need to be checked by a licensed professional.
