This bungalow with double garage plans places a four-bedroom home on one level within a 58'-1" × 40'-4" footprint. Living space is 1,790 sq ft, not counting the garage. The entrance hall (12'-1" × 6'-10") leads into the main living area. The living room is 10'-11" × 29'-4" and runs alongside the dining area (10'-11" × 8'-8") and the open kitchen (8'-10" × 14'-7"). A pantry (6'-4" × 5'-9") and a utility room (6'-4" × 8'-6") support the kitchen, and the 2-car garage (15'-7" × 23'-5") is attached.
The bedrooms are grouped off a narrow bedroom hall (5'-2" × 16'-8"). The primary bedroom (10'-4" × 12'-7") has its own walk-in closet (6'-0" × 5'-6") and ensuite (6'-0" × 6'-8"). Bedroom 2 (14'-11" × 8'-4"), Bedroom 3 (12'-1" × 8'-8") and Bedroom 4 (10'-0" × 10'-1") share the family bathroom (10'-0" × 6'-2"). A study (12'-9" × 8'-4") adds a work or hobby room, and a covered terrace extends the living space outdoors.
Layout highlights
- Living room measures 10'-11" × 29'-4" and sits beside the dining area and open kitchen.
- Primary suite combines a 10'-4" × 12'-7" bedroom, walk-in closet and ensuite.
- Three further bedrooms and a 10'-0" × 6'-2" family bathroom open off one bedroom hall.
- Pantry (6'-4" × 5'-9") and utility room (6'-4" × 8'-6") serve the kitchen.
- Attached 2-car garage measures 15'-7" × 23'-5"; a covered terrace adds outdoor living.
Room sizes
| Room | Size | Area |
|---|---|---|
| Ensuite | 6'-0" × 6'-8" | 40 sq ft |
| Walk-in Closet | 6'-0" × 5'-6" | 33 sq ft |
| Primary Bedroom | 10'-4" × 12'-7" | 130 sq ft |
| Family Bathroom | 10'-0" × 6'-2" | 62 sq ft |
| Bedroom 4 | 10'-0" × 10'-1" | 101 sq ft |
| Bedroom Hall | 5'-2" × 16'-8" | 86 sq ft |
| Bedroom 3 | 12'-1" × 8'-8" | 105 sq ft |
| Entrance Hall | 12'-1" × 6'-10" | 82 sq ft |
| Bedroom 2 | 14'-11" × 8'-4" | 124 sq ft |
| Study | 12'-9" × 8'-4" | 106 sq ft |
| Dining | 10'-11" × 8'-8" | 95 sq ft |
| Living Room | 10'-11" × 29'-4" | 321 sq ft |
| Open Kitchen | 8'-10" × 14'-7" | 128 sq ft |
| Pantry | 6'-4" × 5'-9" | 36 sq ft |
| Utility Room | 6'-4" × 8'-6" | 54 sq ft |
| 2-Car Garage | 15'-7" × 23'-5" | 364 sq ft |
Who this plan suits
This plan suits families who want four bedrooms plus a study on one level, with no stairs and no basement. It needs a lot that can take a 58'-1" × 40'-4" footprint plus setbacks and a driveway to the garage.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 4 bedrooms, 2 baths, bungalow, hall, open kitchen with pantry, dining and living, study, utility room, covered terrace, attached 2-car garage, about 165 m² (1,776 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a bungalow with double garage plan?
A bungalow is a single-story home, and this version adds an attached garage for two cars. Here the garage is 15'-7" × 23'-5" and sits outside the 1,790 sq ft of living space. Everything you live in is on one level.
What affects the lot size and cost of building this plan?
The 58'-1" × 40'-4" footprint sets the minimum lot width and depth once setbacks are added. Because the house is one story, the roof and foundation cover the whole footprint, which usually weighs more in cost than it would on a two-story plan. Local soil, finishes and labor rates change the final figure.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as resizing a bedroom, swapping the study for a fifth bedroom, moving the garage to the other side, or fitting a narrower lot. The plan is regenerated with the new room sizes.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the layout and room sizes. DXF files open in CAD software for drafting and detailing, and the IFC file loads into BIM tools. A local architect or engineer should check the plan against your site and building code before construction.
