This single-story plan has 1,700 sq ft of living space, not counting the carport, on a footprint of 62'-8" × 34'-9". All three bedrooms are suites with their own bathrooms, and a separate guest WC (4'-6" × 6'-2") means visitors never need to enter the bedroom area. The covered carport for two cars (24'-1" × 14'-3") sits at the front, and the laundry measures 8'-4" × 6'-2".
You enter through a 10'-5" × 6'-2" foyer. The kitchen with island (12'-7" × 11'-7") opens to the dining room (10'-4" × 11'-7") and the living room (11'-9" × 27'-3"), with the gourmet balcony as the outdoor extension. A 4'-2" bedroom hall leads to Bedroom 2 (12'-7" × 8'-4"), Bedroom 3 (13'-1" × 8'-4") and the primary suite (19'-6" × 9'-1"), which has a walk-in closet and a primary bath of 11'-3" × 5'-10".
Layout highlights
- Three bedroom suites, each with a private bath, on one level with no stairs.
- Primary suite of 19'-6" × 9'-1" with a 7'-10" × 5'-10" walk-in closet.
- Kitchen with island (12'-7" × 11'-7") opens to the 10'-4" × 11'-7" dining room.
- Living room of 11'-9" × 27'-3" connects to the gourmet balcony.
- Covered carport for two cars at 24'-1" × 14'-3", plus a separate guest WC.
Room sizes
| Room | Size | Area |
|---|---|---|
| Covered Carport (2 cars) | 24'-1" × 14'-3" | 343 sq ft |
| Laundry | 8'-4" × 6'-2" | 51 sq ft |
| Guest WC | 4'-6" × 6'-2" | 28 sq ft |
| Foyer | 10'-5" × 6'-2" | 64 sq ft |
| Kitchen with Island | 12'-7" × 11'-7" | 146 sq ft |
| Dining | 10'-4" × 11'-7" | 120 sq ft |
| Living | 11'-9" × 27'-3" | 320 sq ft |
| Bedroom Hall | 4'-2" × 27'-3" | 114 sq ft |
| Bedroom 3 | 13'-1" × 8'-4" | 109 sq ft |
| Bath 3 | 6'-0" × 8'-4" | 50 sq ft |
| Walk-in Closet | 7'-10" × 5'-10" | 46 sq ft |
| Primary Bath | 11'-3" × 5'-10" | 66 sq ft |
| Primary Suite | 19'-6" × 9'-1" | 178 sq ft |
| Bedroom 2 | 12'-7" × 8'-4" | 105 sq ft |
| Bath 2 | 5'-9" × 8'-4" | 48 sq ft |
Who this plan suits
This plan suits families or hosts who want every bedroom to have its own bathroom, with guests and household sharing no bath. It needs a lot at least wide enough for the 62'-8" × 34'-9" footprint plus setbacks, with street access at the front for the carport.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 3 bedrooms, 3.5 baths, all 3 bedrooms are suites with private bathrooms, guest WC, open kitchen with island, dining, living, gourmet balcony, laundry, covered carport for 2 cars at the front, about 160 m² (1,722 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are house plans with 3 suites?
House plans with 3 suites give each of the three bedrooms its own attached bathroom, so no one shares a bath. This plan adds a guest WC for visitors, which brings the total to 3.5 baths on a single level.
What affects the lot and building cost of this plan?
The 62'-8" × 34'-9" footprint sets the minimum lot size, and one level means a larger foundation and roof area than a two-story home of similar size. Three full bathrooms plus a guest WC add plumbing and fixture cost, and local labor, materials and finishes will decide the final budget.
Can I change this plan by chat?
Yes. You can describe changes such as a different room size, moving the carport to another side, or fitting a narrower lot, and the plan is regenerated to match. Each change is checked against the room layout so the suites, kitchen and living areas still connect.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the floor plan and room sizes, and for sharing with family or a builder. The DXF opens in CAD software for drafting and detailing, and the IFC imports into BIM tools. A local architect or engineer should confirm the plan against your site and building code before construction.
