This one-story barndominium plan has 1,760 sq ft of living space, not counting the shop, on a 51'-6" × 60'-4" footprint. The foyer (5'-1" × 9'-8") leads to a 14'-8" × 27'-8" great room. The kitchen (10'-4" × 16'-10", with an island) and a 10'-4" × 10'-5" dining area form the rest of the main living space.
There are three bedrooms and 2.5 baths. The primary bedroom is 15'-11" × 10'-4" with a 7'-0" × 6'-2" walk-in closet and a 7'-6" × 10'-4" bath. Bedrooms 2 and 3 are each 13'-3" × 8'-10", and the hall bath is 6'-2" × 8'-10". An 11'-5" × 8'-10" laundry and mudroom connects the house to the 49'-6" × 21'-2" shop, which has its own 3'-10" × 8'-10" half bath. A covered porch completes the plan.
Layout highlights
- Great room measures 14'-8" × 27'-8", open to the dining area and kitchen.
- Kitchen with island is 10'-4" × 16'-10", next to a 10'-4" × 10'-5" dining area.
- Primary suite: 15'-11" × 10'-4" bedroom, 7'-0" × 6'-2" walk-in closet, 7'-6" × 10'-4" bath.
- Laundry and mudroom, 11'-5" × 8'-10", sits between the house and the shop.
- Shop is 49'-6" × 21'-2" and includes a 3'-10" × 8'-10" half bath.
Room sizes
| Room | Size | Area |
|---|---|---|
| Kitchen with Island | 10'-4" × 16'-10" | 174 sq ft |
| Dining | 10'-4" × 10'-5" | 107 sq ft |
| Great Room | 14'-8" × 27'-8" | 407 sq ft |
| Foyer | 5'-1" × 9'-8" | 49 sq ft |
| Primary Bath | 7'-6" × 10'-4" | 77 sq ft |
| Primary Bedroom | 15'-11" × 10'-4" | 164 sq ft |
| Bedroom Hall | 16'-4" × 6'-2" | 101 sq ft |
| Walk-in Closet | 7'-0" × 6'-2" | 43 sq ft |
| Bedroom 2 | 13'-3" × 8'-10" | 117 sq ft |
| Shop Half Bath | 3'-10" × 8'-10" | 34 sq ft |
| Laundry / Mudroom | 11'-5" × 8'-10" | 100 sq ft |
| Hall Bath | 6'-2" × 8'-10" | 54 sq ft |
| Bedroom 3 | 13'-3" × 8'-10" | 117 sq ft |
| Shop (30x40 ft) | 49'-6" × 21'-2" | 1,047 sq ft |
Who this plan suits
This plan suits owners who want a single-story home with a working shop for vehicles, equipment, or a trade, entered through a mudroom. It needs a level lot at least 51'-6" wide with room for the 60'-4" depth, plus access to the shop.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Barndominium with a large shop: rectangular metal building, 3 bedrooms, 2 baths, open great room and kitchen with island, laundry/mudroom between house and a 30 x 40 ft shop with a half bath, covered porch, about 1,800 sq ft of living space.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a 3 bedroom barndominium with shop?
It is a barndominium that combines a living area and a workshop under one rectangular building. Here, 1,760 sq ft of living space with three bedrooms and 2.5 baths sits beside a 49'-6" × 21'-2" shop, joined by a laundry and mudroom.
What affects the lot and building cost of this plan?
The 51'-6" × 60'-4" footprint sets the minimum lot width and depth, and the shop adds slab and roof area beyond the living space. Site grading, utilities to the shop half bath, foundation type, and metal building finishes will drive cost more than the room count.
Can I change this plan by chat?
Yes. You can ask for changes such as different room sizes, the shop on the other side, or a narrower or wider lot, and the layout is regenerated. Check the new room dimensions and footprint before you rely on them.
How do I use the PDF, DXF, and IFC files?
The PDF is for review and sharing with builders or lenders. The DXF opens in CAD software for 2D drawing work, and the IFC imports into BIM tools for 3D model coordination. Confirm dimensions and local code requirements with your engineer or designer before construction.
