This two story craftsman plan offers 2,590 square feet of living space, not counting the garage, on a footprint of 56'-5" × 31'-2". The ground floor is organized around a 21'-7" × 16'-6" living room with a fireplace. A front porch leads into a 10'-0" × 6'-8" foyer, with a 10'-0" × 8'-8" office just off the entry. The kitchen (12'-1" × 12'-3") sits beside a 9'-0" × 12'-3" dining room and a 4'-2" × 6'-0" pantry.
From the 22'-1" × 16'-6" two-car garage, an 11'-9" × 5'-10" mudroom connects to the laundry and kitchen, so daily traffic stays out of the main living areas. A powder room is on the ground floor. Upstairs, a 12'-5" × 17'-6" hall serves four bedrooms and two bathrooms. The primary suite is 25'-10" × 9'-4", with a 12'-3" × 7'-0" bath and a 6'-4" × 9'-4" walk-in closet. Bedrooms 2, 3 and 4 share a hall bath.
Layout highlights
- Living room with fireplace measures 21'-7" × 16'-6" and anchors the ground floor.
- Office at 10'-0" × 8'-8" sits beside the foyer, away from the bedrooms.
- Mudroom (11'-9" × 5'-10") links the 2-car garage to the laundry and kitchen.
- Primary suite is 25'-10" × 9'-4" with a 12'-3" × 7'-0" bath and walk-in closet.
- Kitchen, dining room and pantry sit together on the ground floor, with a powder room nearby.
Room sizes
| Room | Level | Size | Area |
|---|---|---|---|
| Dining | 1 | 9'-0" × 12'-3" | 110 sq ft |
| Kitchen | 1 | 12'-1" × 12'-3" | 148 sq ft |
| Pantry | 1 | 4'-2" × 6'-0" | 25 sq ft |
| Laundry | 1 | 6'-10" × 6'-0" | 41 sq ft |
| Powder Room | 1 | 4'-2" × 6'-0" | 25 sq ft |
| Stair | 1 | 8'-8" × 6'-0" | 52 sq ft |
| Mudroom | 1 | 11'-9" × 5'-10" | 69 sq ft |
| Hall | 1 | 12'-11" × 5'-10" | 75 sq ft |
| Foyer | 1 | 10'-0" × 6'-8" | 67 sq ft |
| Office | 1 | 10'-0" × 8'-8" | 86 sq ft |
| Living Room with Fireplace | 1 | 21'-7" × 16'-6" | 357 sq ft |
| 2-Car Garage | 1 | 22'-1" × 16'-6" | 366 sq ft |
| Stair | 2 | 8'-8" × 6'-0" | 52 sq ft |
| Primary Bath | 2 | 12'-3" × 7'-0" | 86 sq ft |
| Bedroom 3 | 2 | 19'-11" × 7'-0" | 140 sq ft |
| Walk-in Closet | 2 | 6'-4" × 9'-4" | 59 sq ft |
| Primary Bedroom | 2 | 25'-10" × 9'-4" | 241 sq ft |
| Upper Hall | 2 | 12'-5" × 17'-6" | 217 sq ft |
| Bedroom 4 | 2 | 11'-11" × 11'-3" | 135 sq ft |
| Hall Bath | 2 | 8'-8" × 7'-2" | 62 sq ft |
| Bedroom 2 | 2 | 8'-8" × 15'-3" | 132 sq ft |
Who this plan suits
This plan suits families who want four bedrooms on one floor and a dedicated office, with everyday entry through the garage and mudroom. It needs a lot that can hold a 56'-5" × 31'-2" footprint plus setbacks and a driveway to the garage.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Two-story craftsman house, 4 bedrooms, 2.5 baths, ground floor living with fireplace, kitchen, dining, office, mudroom; upstairs 4 bedrooms, attached 2-car garage, front porch, about 2,600 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What defines a two story craftsman house plan?
Two story craftsman plans typically combine a covered front porch with a compact, efficient footprint and stacked living levels. This plan places the shared rooms and office on the ground floor and all four bedrooms upstairs, with 2,590 sq ft of living space.
What affects the cost and lot requirements of this plan?
The 56'-5" × 31'-2" footprint sets the minimum lot width and depth once setbacks are added. Foundation type, roof complexity, finishes, and local labor and material rates will drive the build cost, so get local bids against the full plan set.
Can I change this plan by chat?
Yes. You can describe changes such as moving the garage to the other side, resizing or renaming rooms, or fitting a narrower lot. The plan is regenerated so the rooms and circulation stay consistent.
How do I use the PDF, DXF and IFC files?
The PDF is for review, printing and sharing with builders or lenders. The DXF opens in CAD software for drafting and detail work, and the IFC imports into BIM tools for modeling and coordination. Have a local engineer or architect review the plans before permitting.
