This single-story barndominium plan has 1,860 square feet of living space, not counting the garage, within a 49'-3" × 57'-9" footprint. A porch runs along the front, right and left sides. The foyer (9'-8" × 6'-2") opens to a 17'-2" × 25'-5" great room. The dining area (9'-8" × 11'-5") and the kitchen sit alongside it, so the main living space reads as one open zone.
The kitchen measures 7'-10" × 21'-9" and includes an island. A pantry (9'-8" × 3'-5"), a laundry room (4'-6" × 11'-1") and a mudroom (4'-6" × 10'-4") support it and connect to the 2-car garage (16'-10" × 21'-9"). The primary bedroom (10'-0" × 18'-6") has a 11'-3" × 6'-8" bath and a walk-in closet (11'-3" × 4'-10"). Bedrooms 2 and 3 (11'-3" × 10'-5" each) share the hall bath (10'-9" × 5'-6") off the bedroom hall.
Layout highlights
- Porch wraps the front, right and left sides of the 49'-3" × 57'-9" footprint.
- Great room measures 17'-2" × 25'-5" and joins the dining area and kitchen.
- Kitchen is 7'-10" × 21'-9" with an island and a 9'-8" × 3'-5" pantry.
- Primary suite: 10'-0" × 18'-6" bedroom, 11'-3" × 6'-8" bath, 11'-3" × 4'-10" closet.
- Mudroom and laundry sit between the kitchen and the 16'-10" × 21'-9" two-car garage.
Room sizes
| Room | Size | Area |
|---|---|---|
| Great Room | 17'-2" × 25'-5" | 437 sq ft |
| Primary Bedroom | 10'-0" × 18'-6" | 185 sq ft |
| Bedroom Hall | 10'-9" × 8'-10" | 95 sq ft |
| Hall Bath | 10'-9" × 5'-6" | 59 sq ft |
| Primary Bath | 11'-3" × 6'-8" | 76 sq ft |
| Walk-in Closet | 11'-3" × 4'-10" | 55 sq ft |
| Bedroom 2 | 11'-3" × 10'-5" | 118 sq ft |
| Bedroom 3 | 11'-3" × 10'-5" | 118 sq ft |
| Foyer | 9'-8" × 6'-2" | 59 sq ft |
| Dining | 9'-8" × 11'-5" | 110 sq ft |
| Pantry | 9'-8" × 3'-5" | 33 sq ft |
| Kitchen with Island | 7'-10" × 21'-9" | 170 sq ft |
| Laundry | 4'-6" × 11'-1" | 50 sq ft |
| Mudroom | 4'-6" × 10'-4" | 47 sq ft |
| 2-Car Garage | 16'-10" × 21'-9" | 367 sq ft |
Who this plan suits
This plan suits households that want one-level living, a main living space for gatherings, and outdoor space on several sides of the house. It needs a lot wide and deep enough for the 49'-3" × 57'-9" footprint plus setbacks, ideally with views or breezes worth reaching from all three porches.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story barndominium with a wraparound porch on three sides: 3 bedrooms, 2 baths, open great room and kitchen with island, pantry, laundry, 2-car garage, about 1,900 sq ft of living space.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a barndominium with a wrap around porch?
It is a barn-style home, usually a simple rectangular single-story form with a gabled roof, that is built for full-time living and surrounded by a covered porch. This plan has a porch on the front, right and left sides, with 1,860 square feet of enclosed living space.
What affects the cost of building this barndominium plan?
Main drivers include the 49'-3" × 57'-9" footprint, the porch roof that extends over three sides, the foundation type your site needs, and your local labor and material rates. The garage is outside the 1,860 square feet of living space but still adds to the structure you build.
Can I change this plan by chat?
Yes. You can ask for changes such as resizing or moving rooms, switching the garage to another side, or fitting the plan to a narrower or wider lot. The layout is then regenerated so the rooms still connect.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the plan and sharing it with a builder or contractor. The DXF opens in CAD software for drafting and edits, and the IFC imports into BIM tools for coordination. Have a local professional check the plan against your site and building code before construction.
