This single-story plan has 1,640 sq ft of living space, excluding the garage, within a 65'-7" × 36'-5" footprint. You enter through an 8'-4" × 9'-0" entrance hall with a guest WC beside it. The 23'-1" × 12'-11" living room, the 14'-8" × 7'-10" dining area and the 15'-7" × 7'-10" open kitchen form one connected day zone that opens onto the pool terrace.
The bedrooms are grouped in their own wing off a bedroom hall. The primary bedroom measures 12'-11" × 12'-1" and has a 7'-0" × 8'-8" bath and a 5'-2" × 8'-8" walk-in closet. Bedroom 2 is 8'-8" × 12'-1" and bedroom 3 is 13'-5" × 8'-8". They share a 5'-10" × 8'-8" family bath. A 5'-6" × 8'-8" laundry, a 5'-6" × 5'-5" outdoor shower room by the pool and a 24'-9" × 14'-5" two-car garage complete the plan.
Layout highlights
- Living room of 23'-1" × 12'-11" sits beside dining and kitchen, all facing the pool terrace.
- Open kitchen of 15'-7" × 7'-10" runs alongside a 14'-8" × 7'-10" dining area.
- Outdoor shower room of 5'-6" × 5'-5" sits by the pool, so swimmers rinse off outside.
- Primary suite combines a 12'-11" × 12'-1" bedroom, 7'-0" × 8'-8" bath and 5'-2" × 8'-8" closet.
- Attached 24'-9" × 14'-5" garage holds two cars on a single level with no basement.
Room sizes
| Room | Size | Area |
|---|---|---|
| Entrance Hall | 8'-4" × 9'-0" | 75 sq ft |
| Guest WC | 8'-4" × 3'-7" | 30 sq ft |
| Living Room | 23'-1" × 12'-11" | 299 sq ft |
| Primary Bedroom | 12'-11" × 12'-1" | 156 sq ft |
| Bedroom Hall | 9'-5" × 12'-1" | 114 sq ft |
| Bedroom 2 | 8'-8" × 12'-1" | 105 sq ft |
| Primary Bath | 7'-0" × 8'-8" | 61 sq ft |
| Walk-in Closet | 5'-2" × 8'-8" | 45 sq ft |
| Family Bath | 5'-10" × 8'-8" | 51 sq ft |
| Bedroom 3 | 13'-5" × 8'-8" | 116 sq ft |
| Dining | 14'-8" × 7'-10" | 116 sq ft |
| Open Kitchen | 15'-7" × 7'-10" | 122 sq ft |
| Outdoor Shower Room | 5'-6" × 5'-5" | 30 sq ft |
| Laundry | 5'-6" × 8'-8" | 48 sq ft |
| 2-Car Garage | 24'-9" × 14'-5" | 357 sq ft |
Who this plan suits
This plan suits families or couples who want three bedrooms on one level and a living area built around a pool. It needs a lot at least wide enough for the 65'-7" × 36'-5" footprint plus the pool terrace, setbacks and a driveway to the garage.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 3 bedrooms, 2 baths, living, dining and open kitchen opening onto a pool terrace, outdoor shower room by the pool, primary suite, laundry, attached 2-car garage, about 150 m² (1,615 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are house plans with pool?
House plans with pool place the main living spaces next to an outdoor terrace and pool area, so the interior and exterior work as one layout. In this plan the living room, dining area and open kitchen all open onto the pool terrace. An outdoor shower room sits next to the pool.
What affects the cost and lot requirements of this plan?
The main cost drivers are the 1,640 sq ft of living space, the attached two-car garage, the pool and terrace, and the number of wet rooms, which include 3.5 baths, a laundry and an outdoor shower room. The lot must fit the 65'-7" × 36'-5" footprint, the pool and local setbacks. Soil, climate and local labor rates change the final figure.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as resizing or moving rooms, switching the garage to the other side, or adapting the plan to a narrower or wider lot. The layout is then updated and the room sizes are recalculated.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the plan and sharing it with contractors or permit offices. The DXF opens in CAD software for 2D drafting and detailing. The IFC is a BIM format you can import into compatible tools to check the model in 3D and coordinate it with other disciplines.
