This single-story barndominium plan measures 68'-11" × 43'-4" and holds 1,980 sq ft of living space, not counting the 26'-11" × 26'-1" attached shop and garage. A covered front porch opens to a 9'-0" × 7'-4" entry that leads into the great room. The great room is 17'-2" × 24'-6" and shares its space with an 18'-0" × 8'-8" dining area and a 12'-7" × 15'-3" kitchen with island.
A 4'-9" × 11'-1" walk-in pantry serves the kitchen. The 12'-7" × 4'-6" mudroom and the 5'-9" × 10'-0" laundry form a service zone that connects the shop to the house. A 22'-7" × 3'-9" hall serves the sleeping wing: Bedroom 2 at 11'-5" × 10'-0", Bedroom 3 at 12'-1" × 10'-0", and a 5'-2" × 10'-0" hall bath. The primary suite is 12'-7" × 14'-3", with a 7'-10" × 7'-4" walk-in closet and a 7'-6" × 11'-1" bath.
Layout highlights
- Great room of 17'-2" × 24'-6" opens to an 18'-0" × 8'-8" dining area.
- Kitchen with island measures 12'-7" × 15'-3", with a 4'-9" × 11'-1" walk-in pantry.
- Mudroom (12'-7" × 4'-6") and laundry (5'-9" × 10'-0") sit between the shop and living areas.
- Primary suite combines a 12'-7" × 14'-3" bedroom, 7'-10" × 7'-4" closet and 7'-6" × 11'-1" bath.
- Attached shop or garage is 26'-11" × 26'-1" on a 68'-11" × 43'-4" footprint.
Room sizes
| Room | Size | Area |
|---|---|---|
| Shop / Garage | 26'-11" × 26'-1" | 701 sq ft |
| Mudroom | 12'-7" × 4'-6" | 57 sq ft |
| Bedroom Hall | 22'-7" × 3'-9" | 84 sq ft |
| Laundry | 5'-9" × 10'-0" | 57 sq ft |
| Bedroom 2 | 11'-5" × 10'-0" | 114 sq ft |
| Hall Bath | 5'-2" × 10'-0" | 52 sq ft |
| Bedroom 3 | 12'-1" × 10'-0" | 120 sq ft |
| Entry | 9'-0" × 7'-4" | 66 sq ft |
| Primary Walk-in Closet | 7'-10" × 7'-4" | 57 sq ft |
| Great Room | 17'-2" × 24'-6" | 422 sq ft |
| Dining | 18'-0" × 8'-8" | 156 sq ft |
| Primary Bedroom | 12'-7" × 14'-3" | 179 sq ft |
| Primary Bath | 7'-6" × 11'-1" | 83 sq ft |
| Walk-in Pantry | 4'-9" × 11'-1" | 52 sq ft |
| Kitchen with Island | 12'-7" × 15'-3" | 192 sq ft |
Who this plan suits
This plan suits households that want one-level living with a large attached shop for vehicles, tools or storage. It needs a lot that can fit a 68'-11" × 43'-4" footprint plus room for a driveway to the shop.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story barndominium, simple rectangular metal building, 3 bedrooms, 2 baths, large open great room with kitchen island and dining, walk-in pantry, laundry and mudroom, attached shop/garage, covered front porch, about 1,800 sq ft of living space.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 3 bedroom barndominium floor plans?
They are single-family layouts built around a simple rectangular, metal-style building, combining living space and often a shop or garage under one roof. This version has 3 bedrooms, 2 baths and 1,980 sq ft of living space on one level, not counting the shop.
What affects the lot and building cost of this plan?
The 68'-11" × 43'-4" footprint sets the minimum lot width and depth, and the 26'-11" × 26'-1" shop adds to the slab and roof area. Local soil, foundation type, finishes and site utilities will drive cost more than the plan shape does.
Can I change this plan by chat?
Yes. You can describe changes such as resizing rooms, moving the shop to the other side, or fitting a narrower lot, and the layout is updated to match. Each change adjusts the connected rooms so the plan stays coherent.
How do I use the PDF, DXF and IFC files?
The PDF is for review, sharing and early discussions with a builder or designer. The DXF opens in most CAD programs for 2D editing, and the IFC loads into BIM tools for 3D coordination. Have a local engineer or designer check the plan against your codes before construction.
