This single-story plan fits four bedrooms and two baths into 1,360 sq ft of living space, on a footprint of 39'-4" × 34'-5". It has no garage and no basement. The rooms are compact, in the metric European and Latin American manner, so little area goes to circulation.
The entry (5'-6" × 12'-7") leads to the shared living space. The living room (11'-7" × 14'-3"), dining area (11'-7" × 8'-10") and kitchen (11'-7" × 8'-8") share one width and read as a single open room. A bedroom hall (10'-5" × 9'-9") connects the four bedrooms. The primary bedroom (10'-5" × 13'-3") has its own ensuite bath (8'-8" × 6'-0"). The other three bedrooms share the main bath (5'-6" × 10'-5"). The laundry (5'-6" × 8'-8") is a separate room.
Layout highlights
- Four bedrooms open off one hall, which keeps the sleeping zone separate from the living area.
- Primary bedroom measures 10'-5" × 13'-3" and has an ensuite bath of 8'-8" × 6'-0".
- Living, dining and kitchen share an 11'-7" width: living 14'-3" deep, dining 8'-10", kitchen 8'-8".
- Bedrooms 2, 3 and 4 measure 8'-8" × 13'-1", 10'-5" × 8'-8" and 8'-8" × 12'-7".
- Separate laundry of 5'-6" × 8'-8" and a main bath of 5'-6" × 10'-5".
Room sizes
| Room | Size | Area |
|---|---|---|
| Bedroom 4 | 8'-8" × 12'-7" | 109 sq ft |
| Bedroom 2 | 8'-8" × 13'-1" | 113 sq ft |
| Ensuite Bath | 8'-8" × 6'-0" | 52 sq ft |
| Bedroom 3 | 10'-5" × 8'-8" | 90 sq ft |
| Bedroom Hall | 10'-5" × 9'-9" | 102 sq ft |
| Primary Bedroom | 10'-5" × 13'-3" | 138 sq ft |
| Entry | 5'-6" × 12'-7" | 69 sq ft |
| Main Bath | 5'-6" × 10'-5" | 58 sq ft |
| Laundry | 5'-6" × 8'-8" | 48 sq ft |
| Living | 11'-7" × 14'-3" | 165 sq ft |
| Dining | 11'-7" × 8'-10" | 102 sq ft |
| Kitchen | 11'-7" × 8'-8" | 101 sq ft |
Who this plan suits
This plan suits families who want four bedrooms and two baths on one level without a basement or garage. It needs a lot at least wide enough for the 39'-4" × 34'-5" footprint, plus setbacks.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 4 bedrooms, 2 baths, compact plan, 4 bedrooms off one hall, open kitchen, dining and living, laundry, about 125 m² (1,346 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a 4 bedroom house plan of 125 m2?
It is a single-level home with four bedrooms in roughly 125 m2 of living space. This version measures 1,360 sq ft of living area and does not count a garage. Compact rooms and one shared hall keep the footprint small.
What affects the lot and building cost of this plan?
The 39'-4" × 34'-5" footprint sets the minimum lot size, and one level means a larger foundation and roof area than a two-story home of the same size. Local labor, materials, soil and site work will drive the final cost more than the layout. The plan has no basement, which avoids excavation for one.
Can I change this plan by chat?
Yes. You can ask for changes such as swapping room sizes, adding a garage on a chosen side, or fitting a narrower or wider lot. The layout is then regenerated with the new dimensions.
How do I use the PDF, DXF and IFC files?
The PDF is for review, sharing and permit discussions. The DXF opens in CAD software for 2D drafting and edits. The IFC loads into BIM tools so you can inspect the model in 3D. Have a local architect or engineer check the plan against your local codes before construction.
