This single-story plan has 1,660 square feet of living space, not counting the garage, on a footprint of 62'-0" × 34'-9". A front porch leads into a 6'-6" × 10'-0" foyer. The living room, at 23'-5" × 15'-7", opens to the kitchen (10'-1" × 15'-7") and the dining area (10'-4" × 9'-8"), so the main living spaces share one open zone.
The attached two-car garage measures 21'-5" × 16'-10" and connects to a 10'-4" × 5'-6" laundry room. Groceries and laundry stay out of the main rooms. A 27'-6" bedroom hall serves the two secondary bedrooms, each 9'-1" × 12'-11", and the 8'-6" × 6'-6" hall bath. The primary bedroom is 10'-4" × 16'-10" and has a 7'-4" × 10'-0" bath and an 8'-6" × 6'-0" walk-in closet.
Layout highlights
- Living room of 23'-5" × 15'-7" opens directly to the kitchen and dining area.
- Kitchen at 10'-1" × 15'-7" shares its width with the living room.
- Laundry room of 10'-4" × 5'-6" sits between the house and the 21'-5" × 16'-10" garage.
- Bedrooms 2 and 3 are each 9'-1" × 12'-11", served by an 8'-6" × 6'-6" hall bath.
- Primary bedroom of 10'-4" × 16'-10" includes a 7'-4" × 10'-0" bath and 8'-6" × 6'-0" closet.
Room sizes
| Room | Size | Area |
|---|---|---|
| Dining | 10'-4" × 9'-8" | 99 sq ft |
| Laundry Room | 10'-4" × 5'-6" | 57 sq ft |
| Kitchen | 10'-1" × 15'-7" | 157 sq ft |
| Living Room | 23'-5" × 15'-7" | 364 sq ft |
| Foyer | 6'-6" × 10'-0" | 65 sq ft |
| Primary Bath | 7'-4" × 10'-0" | 73 sq ft |
| 2-Car Garage | 21'-5" × 16'-10" | 362 sq ft |
| Bedroom Hall | 27'-6" × 3'-7" | 97 sq ft |
| Bedroom 2 | 9'-1" × 12'-11" | 118 sq ft |
| Bedroom 3 | 9'-1" × 12'-11" | 118 sq ft |
| Hall Bath | 8'-6" × 6'-6" | 55 sq ft |
| Walk-in Closet | 8'-6" × 6'-0" | 51 sq ft |
| Primary Bedroom | 10'-4" × 16'-10" | 174 sq ft |
Who this plan suits
This plan suits households that want one-level living, a garage entry through the laundry room, and three bedrooms in under 1,700 square feet. It needs a lot wider than the 62'-0" footprint once side setbacks are added, with room for the 34'-9" depth and a front porch.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 3 bedrooms, 2 baths, open kitchen and living, dining, laundry room off the garage, attached 2-car garage, front porch, about 1,650 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What should I look for in house plans with a 2 car garage?
Check how the garage connects to the house, and how wide and deep it is. This plan has a 21'-5" × 16'-10" garage that opens into a 10'-4" × 5'-6" laundry room, so the daily entry does not pass through the kitchen or living room.
What affects the lot and building cost of this plan?
The 62'-0" × 34'-9" footprint sets the minimum lot width and the foundation size, and the attached garage and porch add to the roof and slab area. Local setbacks, soil, foundation type, and finish choices will move the cost more than the room layout does.
Can I change this plan by chat?
Yes. You can ask to resize rooms, move the garage to the other side, add or remove a bedroom, or adjust the plan for a narrower or wider lot. The layout is regenerated with the new room sizes and updated drawings.
How do I use the PDF, DXF, and IFC files?
The PDF is for reading and sharing the plan with a builder or lender. The DXF opens in CAD software for editing the 2D drawings, and the IFC imports into BIM tools such as Revit or ArchiCAD. Have a local engineer or designer review the plan against your code before permitting.
