This single-story plan fits four bedrooms and two baths into 1,690 square feet of living space, with the garage not included. The footprint measures 56'-9" by 39'-1". A front porch leads to a 6'-2" by 10'-4" foyer. The main living zone includes a 14'-4" by 19'-6" living room, a 14'-3" by 8'-8" dining area and a 14'-3" by 10'-5" kitchen.
The 22'-5" by 17'-2" two-car garage is paired with a 5'-5" by 7'-10" mudroom and a 5'-5" by 9'-0" laundry. Bedrooms 2, 3 and 4 come off a 9'-4" by 11'-1" bedroom hall and share one 8'-4" by 7'-2" bath. The primary bedroom measures 10'-1" by 16'-2". It has its own 6'-2" by 11'-11" bath and an 8'-4" by 5'-5" walk-in closet.
Layout highlights
- Open kitchen, dining and living room: 14'-3" wide, with a 14'-4" by 19'-6" living room.
- Primary bedroom is 10'-1" by 16'-2" with an 8'-4" by 5'-5" walk-in closet.
- Three secondary bedrooms share one 8'-4" by 7'-2" bath off a 9'-4" by 11'-1" hall.
- Mudroom (5'-5" by 7'-10") and laundry (5'-5" by 9'-0") serve the 22'-5" by 17'-2" garage.
- Front porch opens to a 6'-2" by 10'-4" foyer on a 56'-9" by 39'-1" footprint.
Room sizes
| Room | Size | Area |
|---|---|---|
| Laundry | 5'-5" × 9'-0" | 48 sq ft |
| Mudroom | 5'-5" × 7'-10" | 42 sq ft |
| 2-Car Garage | 22'-5" × 17'-2" | 386 sq ft |
| Kitchen | 14'-3" × 10'-5" | 149 sq ft |
| Dining | 14'-3" × 8'-8" | 123 sq ft |
| Living Room | 14'-4" × 19'-6" | 280 sq ft |
| Foyer | 6'-2" × 10'-4" | 64 sq ft |
| Primary Bath | 6'-2" × 11'-11" | 74 sq ft |
| Bedroom 4 | 9'-4" × 9'-0" | 84 sq ft |
| Bedroom Hall | 9'-4" × 11'-1" | 103 sq ft |
| Bedroom 3 | 8'-4" × 12'-11" | 108 sq ft |
| Shared Bath | 8'-4" × 7'-2" | 60 sq ft |
| Primary Bedroom | 10'-1" × 16'-2" | 164 sq ft |
| Bedroom 2 | 8'-4" × 10'-5" | 87 sq ft |
| Walk-in Closet | 8'-4" × 5'-5" | 45 sq ft |
Who this plan suits
This plan suits families or buyers who want four bedrooms on one level with a private primary suite and an attached garage. It needs a lot at least about 57 feet wide for the footprint, plus the setbacks your local code requires.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 4 bedrooms, 2 baths, open kitchen and living, dining, laundry; two baths shared smartly, attached 2-car garage, front porch, about 1,900 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 4 bedroom 2 bath house plans?
They are home designs with four bedrooms and two full bathrooms, which keeps plumbing and cost lower than plans with a bath for each bedroom. In this plan, one bath serves the primary bedroom and the other is shared by bedrooms 2, 3 and 4.
What affects the lot and building cost of this plan?
The 56'-9" by 39'-1" footprint sets the minimum lot width and depth once setbacks are added. Cost depends on your region, foundation type, finishes and site work. The single-story form with 1,690 sq ft of living space and an attached garage means a larger roof and foundation area than a two-story home of similar size.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as resizing rooms, moving the garage to the other side or fitting a narrower lot. The layout is regenerated so the rooms still connect, and you can review the new room sizes before you use it.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the plan and sharing it with a builder or contractor. The DXF opens in CAD software for drafting and measuring. The IFC imports into BIM tools for modeling. Have a local architect or engineer check the plan against your site and building code before construction.
