This single-story barndominium with 2 master suites measures 71'-6" × 49'-3" and has 2,570 sq ft of living space, not counting the attached shop. The great room (20'-11" × 26'-8") is the center of the plan. The 17'-4" × 11'-3" kitchen and a 14'-1" × 8'-8" dining area sit beside it, with a 4'-5" × 11'-3" pantry next to the kitchen.
Primary Suite 1 (15'-11" × 10'-9") is at one end, with a 9'-4" × 6'-10" walk-in closet and a 12'-5" × 6'-10" bath. Primary Suite 2 (12'-5" × 11'-11") is at the other end, with a 6'-6" × 8'-8" closet and a 12'-11" × 6'-4" bath. West Hall and East Hall connect the ends of the house. Bedrooms 3 and 4 (10'-4" × 10'-8" and 10'-8" × 10'-8") share a 5'-10" × 10'-9" hall bath. The 25'-9" × 28'-4" shop connects through a 9'-0" × 6'-2" mudroom, close to the 12'-11" × 5'-2" laundry.
Layout highlights
- Two primary suites at opposite ends, each with its own walk-in closet and private bath.
- Great room of 20'-11" × 26'-8" anchors the center, open to the kitchen and dining.
- Kitchen of 17'-4" × 11'-3" with a 4'-5" × 11'-3" pantry alongside.
- Attached shop of 25'-9" × 28'-4" enters through a 9'-0" × 6'-2" mudroom.
- Bedrooms 3 and 4 at about 10'-8" × 10'-8" share a 5'-10" × 10'-9" hall bath.
Room sizes
| Room | Size | Area |
|---|---|---|
| Attached Shop | 25'-9" × 28'-4" | 729 sq ft |
| Mudroom | 9'-0" × 6'-2" | 55 sq ft |
| East Hall | 16'-4" × 6'-2" | 101 sq ft |
| Laundry | 12'-11" × 5'-2" | 67 sq ft |
| Primary Bath 2 | 12'-11" × 6'-4" | 82 sq ft |
| Primary Suite 2 | 12'-5" × 11'-11" | 148 sq ft |
| Foyer | 6'-8" × 10'-4" | 69 sq ft |
| Great Room | 20'-11" × 26'-8" | 559 sq ft |
| Walk-in Closet 2 | 6'-6" × 8'-8" | 56 sq ft |
| Dining | 14'-1" × 8'-8" | 122 sq ft |
| Bedroom 3 | 10'-4" × 10'-8" | 110 sq ft |
| Bedroom 4 | 10'-8" × 10'-8" | 113 sq ft |
| West Hall | 22'-1" × 6'-2" | 136 sq ft |
| Hall Bath | 5'-10" × 10'-9" | 63 sq ft |
| Primary Suite 1 | 15'-11" × 10'-9" | 171 sq ft |
| Primary Bath 1 | 12'-5" × 6'-10" | 85 sq ft |
| Walk-in Closet 1 | 9'-4" × 6'-10" | 64 sq ft |
| Kitchen | 17'-4" × 11'-3" | 196 sq ft |
| Pantry | 4'-5" × 11'-3" | 50 sq ft |
Who this plan suits
This plan suits two households sharing one home, such as multigenerational families or owners who want a guest suite with real privacy, and anyone who needs shop space attached to the house. It needs a lot that fits the 71'-6" × 49'-3" footprint plus setbacks, with room for vehicle access to the shop.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story barndominium with 2 master suites at opposite ends (each with walk-in closet and bath), 2 more bedrooms and a hall bath, open great room and kitchen, laundry, attached shop, porch, about 2,600 sq ft of living space.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
