This two-story plan has 2,480 square feet of living space, not counting the garage, on a footprint of 41'-8" × 36'-1". From the front porch, the foyer (10'-8" × 6'-10") leads to the stair and into a ground floor where the kitchen (11'-11" × 13'-1"), dining area (11'-11" × 9'-4") and family room (11'-1" × 22'-9") share one open space. An office (10'-8" × 9'-4") and a powder room sit off the entry.
A mudroom and laundry (5'-1" × 10'-11") handles the entry from the attached 2-car garage. Upstairs, the primary bedroom (15'-7" × 13'-9") has a 10'-0" × 7'-0" bath and a 6'-6" × 7'-0" walk-in closet. Bedrooms 2, 3 and 4 share a 7'-2" × 7'-0" hall bath, and a 19'-6" × 12'-7" bonus room sits over the garage.
Layout highlights
- Kitchen, dining and family room share one open ground-floor space, with a 11'-1" × 22'-9" family room.
- Office (10'-8" × 9'-4") and powder room are on the ground floor, near the foyer.
- Primary suite has a 15'-7" × 13'-9" bedroom, 10'-0" × 7'-0" bath and 6'-6" × 7'-0" closet.
- Bedroom 2 is 10'-8" × 16'-6"; bedroom 3 is 8'-10" × 12'-7"; bedroom 4 is 10'-8" × 10'-11".
- Bonus room over the garage measures 19'-6" × 12'-7", with a mudroom and laundry below at the entry.
Room sizes
| Room | Level | Size | Area |
|---|---|---|---|
| Dining | 1 | 11'-11" × 9'-4" | 111 sq ft |
| Kitchen | 1 | 11'-11" × 13'-1" | 156 sq ft |
| Family Room | 1 | 11'-1" × 22'-9" | 252 sq ft |
| Office | 1 | 10'-8" × 9'-4" | 99 sq ft |
| Foyer | 1 | 10'-8" × 6'-10" | 73 sq ft |
| Powder Room | 1 | 4'-10" × 5'-10" | 28 sq ft |
| Stair | 1 | 10'-8" × 5'-1" | 54 sq ft |
| Mudroom / Laundry | 1 | 5'-1" × 10'-11" | 55 sq ft |
| 2-Car Garage | 1 | 34'-3" × 10'-11" | 375 sq ft |
| Stair | 2 | 10'-8" × 5'-10" | 62 sq ft |
| Bonus Room over Garage | 2 | 19'-6" × 12'-7" | 246 sq ft |
| Bedroom 3 | 2 | 8'-10" × 12'-7" | 111 sq ft |
| Primary Bedroom | 2 | 15'-7" × 13'-9" | 213 sq ft |
| Upstairs Hall | 2 | 12'-9" × 13'-9" | 175 sq ft |
| Primary Bath | 2 | 10'-0" × 7'-0" | 70 sq ft |
| Walk-in Closet | 2 | 6'-6" × 7'-0" | 46 sq ft |
| Hall Bath | 2 | 7'-2" × 7'-0" | 50 sq ft |
| Linen / Storage | 2 | 3'-10" × 7'-0" | 27 sq ft |
| Bedroom 2 | 2 | 10'-8" × 16'-6" | 176 sq ft |
| Bedroom 4 | 2 | 10'-8" × 10'-11" | 116 sq ft |
Who this plan suits
This plan suits households that want four bedrooms upstairs and a connected living area downstairs, with an office for working from home. It needs a lot that fits the 41'-8" × 36'-1" footprint plus setbacks and a driveway to the attached garage.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Two-story house, 4 bedrooms, 2.5 baths, ground floor open kitchen, dining and family room in one space, office, powder room; upstairs 4 bedrooms, attached 2-car garage, front porch, about 2,500 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a 4 bedroom open floor plan house plan?
It is a home design with four bedrooms where the main living spaces are combined rather than separated by walls. In this plan, the kitchen, dining area and family room share one ground-floor space, and all four bedrooms are upstairs.
What affects the lot and building cost for this plan?
The 41'-8" × 36'-1" footprint sets the minimum lot width and depth once setbacks are added. Cost drivers include the 2,480 sq ft of living space, the two stories, the attached 2-car garage, the front porch, and local labor, materials and foundation conditions.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as resizing rooms, moving the garage to the other side, or fitting a narrower lot. The layout is then updated, and you can review the revised plan before you download it.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing and sharing the plan sheets. The DXF opens in CAD software for drafting and editing, and the IFC imports into BIM tools. Have a local architect or engineer check the plan against your site and building code before construction.
