This two-story plan has 1,960 sq ft of living space, not counting the garage, with 4 bedrooms and 3 bathrooms. The footprint is 49'-6" × 27'-7". The ground floor holds the shared rooms: a 20'-6" × 12'-7" living room, a 9'-1" dining area and an 8'-10" kitchen, all 12'-7" deep. A utility room, a shower room and a guest bedroom sit on the same level, beside the 26'-6" × 12'-7" two-car garage.
An 8'-0" × 7'-0" stair leads to a 25'-7" landing that serves every upstairs room. The primary bedroom measures 21'-2" × 10'-1" and opens to a 6'-4" × 9'-0" dressing room and an 11'-3" × 5'-9" bathroom. Bedroom 2 is 14'-4" × 9'-0", Bedroom 3 is 8'-0" × 18'-2", and a 9'-5" × 5'-9" family bathroom serves both. There is no basement.
Layout highlights
- Living room, dining and kitchen run along one 12'-7" deep strip, with the living room at 20'-6" long.
- Ground floor guest bedroom (8'-4" × 12'-7") sits next to a 6'-10" × 6'-0" shower room.
- Utility room (6'-10" × 6'-2") keeps laundry and household storage off the kitchen.
- Primary suite upstairs: 21'-2" × 10'-1" bedroom, 6'-4" × 9'-0" dressing room, 11'-3" × 5'-9" bath.
- Two-car garage, 26'-6" × 12'-7", is attached and not counted in the 1,960 sq ft.
Room sizes
| Room | Level | Size | Area |
|---|---|---|---|
| Entrance Hall | 1 | 4'-9" × 12'-7" | 60 sq ft |
| 2-Car Garage | 1 | 26'-6" × 12'-7" | 334 sq ft |
| Shower Room | 1 | 6'-10" × 6'-0" | 41 sq ft |
| Utility Room | 1 | 6'-10" × 6'-2" | 42 sq ft |
| Guest Bedroom | 1 | 8'-4" × 12'-7" | 105 sq ft |
| Living Room | 1 | 20'-6" × 12'-7" | 258 sq ft |
| Dining | 1 | 9'-1" × 12'-7" | 115 sq ft |
| Kitchen | 1 | 8'-10" × 12'-7" | 111 sq ft |
| Hall | 1 | 8'-0" × 5'-2" | 41 sq ft |
| Stair | 1 | 8'-0" × 7'-0" | 56 sq ft |
| Stair | 2 | 8'-0" × 7'-0" | 56 sq ft |
| Primary Bathroom | 2 | 11'-3" × 5'-9" | 64 sq ft |
| Family Bathroom | 2 | 9'-5" × 5'-9" | 54 sq ft |
| Primary Bedroom | 2 | 21'-2" × 10'-1" | 214 sq ft |
| Dressing Room | 2 | 6'-4" × 9'-0" | 57 sq ft |
| Bedroom 2 | 2 | 14'-4" × 9'-0" | 129 sq ft |
| Landing | 2 | 3'-3" × 25'-7" | 82 sq ft |
| Bedroom 3 | 2 | 8'-0" × 18'-2" | 146 sq ft |
Who this plan suits
This plan suits families who want a bedroom and shower room on the entry level for guests or relatives, with the primary suite and two more bedrooms upstairs. It needs a lot that fits a 49'-6" × 27'-7" footprint plus access to the garage.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Two-story house, 4 bedrooms, 3 baths, ground floor guest bedroom with shower room, open kitchen, dining, living, utility room; upstairs primary suite with dressing room and 2 bedrooms, attached 2-car garage, about 180 m² (1,938 sq ft) of living space (garage not included). Metric European / Latin American layout: compact rooms, no basement.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 180 square meter house plans?
They are designs with roughly 180 m² of living area, which is a mid-to-large family home. This plan has 1,960 sq ft of living space across two levels, with 4 bedrooms and 3 baths. The attached garage is not included in that figure.
What affects the lot and building cost of this plan?
The 49'-6" × 27'-7" footprint sets the minimum lot width and depth once you add setbacks and a driveway to the garage. Cost depends mostly on local labor, foundation type, finishes and the three bathrooms and kitchen. The plan has no basement, which keeps excavation simple.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as moving the garage to the other side, adjusting room sizes, adding or removing a bedroom, or fitting a narrower lot. The layout is updated and the rooms are re-measured.
How do I use the PDF, DXF and IFC files?
The PDF gives you dimensioned floor plans to review and share with a builder or permit office. The DXF opens in CAD software for drafting and edits. The IFC loads into BIM tools so an architect or engineer can build on the model.
