This single-story plan has 1,710 sq ft of living space, 3 bedrooms and 2 baths. The garage is not counted in that figure. A front porch opens to a 7'-6" × 8'-8" foyer and then to the main living area. The living room measures 10'-11" × 31'-0". The kitchen (11'-11" × 13'-5") and dining area (11'-11" × 8'-8") share the same open zone.
A mudroom and laundry (11'-11" × 8'-2") works as the everyday entry beside the attached 2-car garage (20'-2" × 17'-6"). The bedrooms are reached by a 20'-10" × 4'-10" hall. The primary bedroom is 10'-0" × 16'-8", with a 9'-0" × 8'-8" bath and a 6'-6" × 7'-10" walk-in closet. Bedroom 2 (9'-8" × 12'-3") and Bedroom 3 (10'-9" × 12'-3") share a 6'-6" × 8'-6" hall bath. The overall footprint is 43'-4" × 50'-10".
Layout highlights
- Living room runs 10'-11" × 31'-0", giving one long space for seating and circulation.
- Kitchen at 11'-11" × 13'-5" sits beside an 11'-11" × 8'-8" dining area.
- Mudroom and laundry combined in 11'-11" × 8'-2" next to the 2-car garage.
- Primary suite includes a 10'-0" × 16'-8" bedroom, 9'-0" × 8'-8" bath and walk-in closet.
- Bedrooms 2 and 3 are both 12'-3" deep and share a 6'-6" × 8'-6" bath.
Room sizes
| Room | Size | Area |
|---|---|---|
| Dining | 11'-11" × 8'-8" | 103 sq ft |
| Kitchen | 11'-11" × 13'-5" | 160 sq ft |
| Mudroom / Laundry | 11'-11" × 8'-2" | 97 sq ft |
| Living Room | 10'-11" × 31'-0" | 339 sq ft |
| Foyer | 7'-6" × 8'-8" | 65 sq ft |
| Primary Bath | 9'-0" × 8'-8" | 78 sq ft |
| Walk-in Closet | 6'-6" × 7'-10" | 51 sq ft |
| Hall Bath | 6'-6" × 8'-6" | 55 sq ft |
| Primary Bedroom | 10'-0" × 16'-8" | 166 sq ft |
| 2-Car Garage | 20'-2" × 17'-6" | 353 sq ft |
| Bedroom Hall | 20'-10" × 4'-10" | 101 sq ft |
| Bedroom 3 | 10'-9" × 12'-3" | 132 sq ft |
| Bedroom 2 | 9'-8" × 12'-3" | 118 sq ft |
Who this plan suits
This plan suits households that want three bedrooms and one-level living in about 1,710 sq ft, with a dedicated mudroom and laundry. It needs a lot that fits the 43'-4" × 50'-10" footprint plus setbacks and a driveway to the garage.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 3 bedrooms, 2 baths, open kitchen, dining and living, laundry, mudroom, attached 2-car garage, front porch, about 1,700 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are 1700 sq ft house plans?
They are plans with roughly 1,700 sq ft of heated living space, usually not counting the garage. This one measures 1,710 sq ft on a single level, with 3 bedrooms and 2 baths.
What affects the lot and building cost of this plan?
The 43'-4" × 50'-10" footprint sets the minimum lot width and depth once setbacks are added. Cost depends mainly on local labor, foundation type, site grading, roof complexity and finish choices. A single-story layout spreads the same area over a larger foundation and roof than a two-story plan.
Can I change this plan by chat?
Yes. You can ask to resize rooms, move the garage to the other side, or adjust the plan for a narrower lot. The layout is regenerated so the rooms still connect, and you can review the updated sizes before using it.
How do I use the PDF, DXF and IFC files?
The PDF is for reading and sharing the floor plan and dimensions. The DXF opens in CAD software for drafting and editing, and the IFC imports into BIM tools such as Revit or ArchiCAD. Have a local architect or engineer review the plan against your code and site before construction.
