This single-story barndominium plan fits 1,800 square feet of living space, not counting the garage, into a simple 52'-2" × 44'-11" rectangle. The front porch leads to a 7'-0" × 8'-4" foyer and then into the 20'-3" × 18'-10" great room. The kitchen with island (8'-8" × 18'-8") and the dining area (8'-8" × 12'-3") sit alongside it, so cooking, eating and sitting share one open space.
The attached 2-car garage, 20'-3" × 19'-2", sits under the same roof and connects through an 8'-8" × 5'-6" mudroom. The laundry (8'-8" × 5'-5") and a 9'-9" × 4'-2" walk-in pantry are beside it, so groceries come straight in from the garage. The primary bedroom (12'-3" × 13'-5") has a 7'-4" × 10'-0" bath and a 4'-6" × 10'-0" walk-in closet. Bedroom 2 (12'-3" × 9'-4") and Bedroom 3 (7'-10" × 16'-2") share the hall bath.
Layout highlights
- Great room measures 20'-3" × 18'-10" and opens to the kitchen and dining area.
- Kitchen with island runs 8'-8" × 18'-8", next to a 9'-9" × 4'-2" walk-in pantry.
- Garage entry passes through an 8'-8" × 5'-6" mudroom, with the laundry alongside.
- Primary suite combines a 12'-3" × 13'-5" bedroom, 7'-4" × 10'-0" bath and walk-in closet.
- Two secondary bedrooms share a 7'-10" × 6'-2" hall bath off the bedroom hall.
Room sizes
| Room | Size | Area |
|---|---|---|
| Bedroom 2 | 12'-3" × 9'-4" | 114 sq ft |
| Primary Bedroom | 12'-3" × 13'-5" | 164 sq ft |
| Primary Bath | 7'-4" × 10'-0" | 73 sq ft |
| Walk-in Closet | 4'-6" × 10'-0" | 45 sq ft |
| Foyer | 7'-0" × 8'-4" | 59 sq ft |
| Hall Bath | 7'-10" × 6'-2" | 48 sq ft |
| Bedroom Hall | 7'-10" × 11'-1" | 87 sq ft |
| Bedroom 3 | 7'-10" × 16'-2" | 127 sq ft |
| Great Room | 20'-3" × 18'-10" | 382 sq ft |
| Linen/Storage | 10'-1" × 4'-2" | 42 sq ft |
| Walk-in Pantry | 9'-9" × 4'-2" | 41 sq ft |
| 2-Car Garage | 20'-3" × 19'-2" | 388 sq ft |
| Dining | 8'-8" × 12'-3" | 106 sq ft |
| Kitchen with Island | 8'-8" × 18'-8" | 161 sq ft |
| Mudroom | 8'-8" × 5'-6" | 48 sq ft |
| Laundry | 8'-8" × 5'-5" | 47 sq ft |
Who this plan suits
This plan suits households that want one-level living, a drop zone from the garage and an open main space. It needs a lot that can hold a 52'-2" × 44'-11" footprint plus setbacks, driveway access to the garage and room for the front porch.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story barndominium in a simple rectangle: 3 bedrooms, 2 baths, open great room with kitchen island and dining, walk-in pantry, mudroom and laundry from an attached 2-car garage under the same roof, front porch, about 1,800 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a barndominium with garage floor plan?
It is a barndominium-style home, usually a simple rectangle with a gable roof and open interior, that includes a garage within the same structure. In this plan the 2-car garage is attached under the same roof and enters through the mudroom. The 1,800 sq ft of living space does not include the garage.
What affects the lot and building cost of this plan?
The 52'-2" × 44'-11" rectangular footprint is simple to frame and roof, which helps keep the structure straightforward. Cost will still depend on your foundation type, local labor and material prices, finishes and site work. The lot must fit the footprint, setbacks and a driveway to the garage.
Can I change this plan by chat?
Yes. You can ask for changes such as moving the garage to the other side, resizing or swapping rooms, adding a bedroom or fitting a narrower or wider lot. The layout is regenerated so the rooms still connect, and you can review the result before downloading.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the plan and sharing it with a builder, designer or permit office. The DXF opens in CAD software for drafting and edits. The IFC loads into BIM tools so you can inspect the model in 3D. Local code review and engineering are still needed before construction.
