This single-story plan provides 1,970 sq ft of living space, not counting the garages, on a footprint of 74'-6" × 41'-4". It has 3 bedrooms and 2 baths. The RV garage and the 2-car garage (23'-5" × 14'-11") sit side by side at one end of the house. The RV bay is sized for a 14 ft wide, 45 ft deep vehicle and measures 28'-6" × 20'-10" in the plan. Both garages lead to the interior through a mudroom (11'-11" × 5'-6") with the laundry (11'-1" × 5'-6") next to it.
From the front porch, the foyer (11'-1" × 5'-9") opens to the great room (19'-6" × 18'-2"). The kitchen (18'-10" × 8'-10"), a pantry (4'-1" × 9'-0") and the dining area (14'-4" × 9'-0") are open to that room. The primary suite (10'-9" × 20'-10") has a bath (8'-8" × 9'-5") and a walk-in closet (8'-8" × 5'-5"). Bedrooms 2 and 3 share a hall bath with an office (11'-3" × 8'-0") nearby, off the bedroom hall.
Layout highlights
- RV bay for a 14 x 45 ft vehicle, with a 28'-6" × 20'-10" garage footprint
- Separate 2-car garage at 23'-5" × 14'-11" beside the RV bay
- Mudroom (11'-11" × 5'-6") and laundry (11'-1" × 5'-6") sit between the garages and the kitchen
- Great room (19'-6" × 18'-2"), kitchen and dining (14'-4" × 9'-0") share one open space
- Primary suite of 10'-9" × 20'-10" with an 8'-8" × 9'-5" bath and walk-in closet
Room sizes
| Room | Size | Area |
|---|---|---|
| Pantry | 4'-1" × 9'-0" | 37 sq ft |
| Dining | 14'-4" × 9'-0" | 129 sq ft |
| Kitchen | 18'-10" × 8'-10" | 166 sq ft |
| Great Room | 19'-6" × 18'-2" | 354 sq ft |
| Foyer | 11'-1" × 5'-9" | 63 sq ft |
| Hall Bath | 11'-1" × 5'-2" | 57 sq ft |
| Office | 11'-3" × 8'-0" | 90 sq ft |
| Bedroom Hall | 12'-1" × 9'-9" | 118 sq ft |
| Mudroom | 11'-11" × 5'-6" | 66 sq ft |
| Laundry | 11'-1" × 5'-6" | 61 sq ft |
| 2-Car Garage | 23'-5" × 14'-11" | 349 sq ft |
| RV Garage (14 x 45 ft) | 28'-6" × 20'-10" | 592 sq ft |
| Primary Bedroom | 10'-9" × 20'-10" | 224 sq ft |
| Bedroom 3 | 8'-8" × 11'-11" | 103 sq ft |
| Bedroom 2 | 8'-8" × 11'-5" | 99 sq ft |
| Primary Bath | 8'-8" × 9'-5" | 82 sq ft |
| Walk-in Closet | 8'-8" × 5'-5" | 47 sq ft |
Who this plan suits
This plan suits owners of a motorhome, trailer or large toy hauler who want to store it indoors and live on one level. It needs a lot at least 74'-6" wide for the footprint, plus room for a driveway and turning space to reach the 14 ft wide RV bay.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house with an attached RV garage (one 14 ft wide x 45 ft deep RV bay) plus a 2-car garage: 3 bedrooms, 2 baths, open kitchen and great room, dining, mudroom, laundry, about 2,000 sq ft of living space (garages not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are house plans with an RV garage?
They are home designs that include a tall, deep garage bay for a motorhome or trailer, in addition to or instead of a standard car garage. In this plan the RV bay is sized for a 14 ft wide, 45 ft deep vehicle and sits next to a 2-car garage.
What affects the lot and cost of building this plan?
The footprint is 74'-6" × 41'-4", so the lot needs enough width for the house plus a driveway approach to the RV bay. Cost drivers include the large garage slab and door, the taller roof framing over the RV bay, and local labor and material rates.
Can I change this plan by chat?
Yes. You can ask for changes in plain language, such as moving the garages to the other side, adding or removing a bedroom, resizing rooms, or fitting a narrower or wider lot. The plan is regenerated with the new layout.
How do I use the PDF, DXF and IFC files?
The PDF is for review, sharing and permit-set preparation. The DXF opens in CAD software for editing the 2D drawings, and the IFC loads into BIM tools for a 3D model. A local designer or engineer should review the files before construction.
