This single-story barndominium plan measures 60'-0" × 52'-6" and has 2,370 sq ft of living space, not counting the 19'-10" × 25'-9" attached 2-car shop garage. A front porch leads into a 6'-2" × 11'-7" foyer. The open great room, 21'-3" × 22'-1", is the center of the plan. The dining area (11'-5" × 11'-3") and the kitchen with island (9'-5" × 20'-6") share the same open space, and a 4'-6" × 8'-10" pantry supports the kitchen.
The three secondary bedrooms are grouped along a 6'-2" × 22'-3" bedroom hall. Bedrooms 2 and 4 are 9'-8" × 13'-5", and bedroom 3 is 9'-8" × 12'-3". Bath 2 (6'-2" × 8'-4") and Bath 3 (6'-6" × 8'-10") serve the household, and the office measures 8'-10" × 10'-4". The primary bedroom is 12'-11" × 14'-3", with a 7'-2" × 9'-9" walk-in closet and a 5'-9" × 13'-3" bath. A 5'-9" × 10'-9" mudroom and a 6'-2" × 9'-9" laundry complete the service rooms.
Layout highlights
- Great room of 21'-3" × 22'-1" with the 11'-5" × 11'-3" dining area and island kitchen
- Kitchen with island measures 9'-5" × 20'-6", with a 4'-6" × 8'-10" pantry
- Primary suite combines a 12'-11" × 14'-3" bedroom, 7'-2" × 9'-9" closet and 5'-9" × 13'-3" bath
- Three more bedrooms, 9'-8" wide, open off a 6'-2" × 22'-3" hall
- Attached 19'-10" × 25'-9" shop garage, plus a 5'-9" × 10'-9" mudroom and laundry
Room sizes
| Room | Size | Area |
|---|---|---|
| Office | 8'-10" × 10'-4" | 91 sq ft |
| Bedroom 2 | 9'-8" × 13'-5" | 129 sq ft |
| Bedroom 4 | 9'-8" × 13'-5" | 129 sq ft |
| Bedroom 3 | 9'-8" × 12'-3" | 118 sq ft |
| Foyer | 6'-2" × 11'-7" | 72 sq ft |
| Bedroom Hall | 6'-2" × 22'-3" | 137 sq ft |
| Bath 2 | 6'-2" × 8'-4" | 51 sq ft |
| Great Room | 21'-3" × 22'-1" | 470 sq ft |
| Bath 3 | 6'-6" × 8'-10" | 57 sq ft |
| Pantry | 4'-6" × 8'-10" | 40 sq ft |
| Dining | 11'-5" × 11'-3" | 129 sq ft |
| Kitchen with Island | 9'-5" × 20'-6" | 193 sq ft |
| Primary Bedroom | 12'-11" × 14'-3" | 184 sq ft |
| Walk-in Closet | 7'-2" × 9'-9" | 70 sq ft |
| Laundry | 6'-2" × 9'-9" | 60 sq ft |
| Primary Bath | 5'-9" × 13'-3" | 76 sq ft |
| Mudroom | 5'-9" × 10'-9" | 61 sq ft |
| 2-Car Shop Garage | 19'-10" × 25'-9" | 510 sq ft |
Who this plan suits
This plan suits families who want four bedrooms and a dedicated office on one level, with a garage large enough to double as a workshop. It needs a lot that can fit a 60'-0" × 52'-6" footprint plus the porch, driveway and setbacks.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story barndominium, rectangular metal building, 4 bedrooms, 3 baths, primary suite with walk-in closet, open great room and kitchen with island, office, laundry, mudroom, attached 2-car shop garage, porch, about 2,400 sq ft of living space.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What is a 4 bedroom barndominium floor plan?
A 4 bedroom barndominium floor plan places four bedrooms in a rectangular, metal-building style home. This version has 2,370 sq ft of living space, 3 baths, an open great room and kitchen, and an attached 2-car shop garage on a single level.
What affects the lot and building cost of this plan?
The 60'-0" × 52'-6" footprint sets the minimum lot width and depth once setbacks and a driveway to the garage are added. Cost drivers include foundation type, soil conditions, local codes, finish level and the size of the garage, which is not counted in the 2,370 sq ft.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as moving the garage to the other side, resizing a bedroom, dropping the office or fitting a narrower lot. The layout is regenerated so the rooms still connect, and you can review the new plan before using it.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing and sharing the plan with family, a builder or a designer. The DXF opens in common CAD programs for editing and drafting, and the IFC loads into BIM tools for 3D coordination. Have a licensed professional check the plan against local codes before construction.
