This single-story plan has 2,470 sq ft of living space, not counting the garage, on a footprint of 50'-6" × 59'-5". It has four bedrooms and three baths. The guest suite sits near the entry and the 11'-5" × 8'-0" foyer. It is 9'-10" × 11'-9" and has its own 9'-10" × 5'-1" bath, so visitors have privacy without crossing the main living areas.
The great room measures 20'-11" × 20'-7" and connects to the 11'-7" × 13'-9" kitchen and the 11'-7" × 10'-1" dining area. A pantry, a 4'-6" × 15'-3" mudroom and a laundry room support the kitchen and the 2-car garage. At the back, the 14'-3" × 17'-2" primary bedroom has a 10'-4" × 9'-4" bath and a 10'-4" × 7'-6" walk-in closet. Bedrooms 2 and 3 and a 10'-11" × 10'-1" office open off a long bedroom hall, and the two bedrooms share a bath.
Layout highlights
- Guest suite of 9'-10" × 11'-9" with a private 9'-10" × 5'-1" bath, near the entry.
- Primary suite at the back: 14'-3" × 17'-2" bedroom, 10'-4" × 9'-4" bath, 10'-4" × 7'-6" closet.
- Great room of 20'-11" × 20'-7" opens to the kitchen and the 11'-7" × 10'-1" dining area.
- Kitchen of 11'-7" × 13'-9" with a 6'-8" × 6'-2" pantry, plus a mudroom and laundry.
- Bedrooms 2 and 3 are each 10'-11" × 11'-9", with an office and shared bath nearby.
Room sizes
| Room | Size | Area |
|---|---|---|
| Primary Bath | 10'-4" × 9'-4" | 96 sq ft |
| Walk-in Closet | 10'-4" × 7'-6" | 77 sq ft |
| Primary Bedroom | 14'-3" × 17'-2" | 245 sq ft |
| Foyer | 11'-5" × 8'-0" | 91 sq ft |
| Guest Bath | 9'-10" × 5'-1" | 50 sq ft |
| Guest Suite | 9'-10" × 11'-9" | 116 sq ft |
| Office | 10'-11" × 10'-1" | 111 sq ft |
| Bedroom 3 | 10'-11" × 11'-9" | 129 sq ft |
| Bedroom 2 | 10'-11" × 11'-9" | 129 sq ft |
| Shared Bath | 10'-11" × 5'-1" | 55 sq ft |
| Bedroom Hall | 3'-10" × 39'-10" | 154 sq ft |
| Great Room | 20'-11" × 20'-7" | 431 sq ft |
| 2-Car Garage | 20'-11" × 18'-10" | 394 sq ft |
| Dining | 11'-7" × 10'-1" | 117 sq ft |
| Kitchen | 11'-7" × 13'-9" | 159 sq ft |
| Mudroom | 4'-6" × 15'-3" | 69 sq ft |
| Pantry | 6'-8" × 6'-2" | 41 sq ft |
| Laundry | 6'-8" × 8'-8" | 58 sq ft |
Who this plan suits
This plan suits households that host visitors or relatives often and want one bedroom with its own bath away from the family bedrooms. It needs a lot wider than the 50'-6" × 59'-5" footprint once setbacks are added, with room for a front porch and a 2-car garage.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 4 bedrooms, 3 baths, guest suite with its own bath near the entry, primary suite at the back, open kitchen, great room, laundry, attached 2-car garage, front porch, about 2,500 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are house plans with a guest suite?
They are plans that include a bedroom with its own bath, set apart from the other bedrooms. Here the guest suite is 9'-10" × 11'-9" with a 9'-10" × 5'-1" bath and sits near the entry. Guests can come and go without passing the primary suite or the bedroom hall.
What affects the lot and building cost of this plan?
The main drivers are the 50'-6" × 59'-5" footprint, the 2,470 sq ft of living space and the 20'-11" × 18'-10" garage. The single story spreads the foundation and roof over a larger area than a two-story plan of the same size. Local setbacks, soil and finishes will change the final cost more than the layout does.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as resizing a room, moving the garage to the other side or fitting a narrower lot. The plan is then regenerated with the new dimensions. Each change can affect nearby rooms, so review the updated layout before you rely on it.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing the plan and sharing it with others. The DXF opens in CAD software for drafting and measuring. The IFC file imports into BIM tools for coordination with a designer or engineer. A local professional should check the plan against your site and code requirements before construction.
