This single-story plan offers 1,090 square feet of living space, not counting the garage, within a footprint of 34'-9" × 40'-8". A front porch leads directly into the living room, which measures 11'-11" × 21'-2". The kitchen (8'-8" × 12'-9") and dining area (8'-8" × 10'-11") open to the living room, so cooking, eating and sitting share one open main living area.
A 4'-2" × 16'-4" bedroom hall separates the sleeping rooms from the open main living area. Bedroom 2 (10'-8" × 9'-8") and the hall bath (6'-0" × 6'-10") open off it. The primary bedroom (10'-8" × 11'-11") has its own bath at 6'-0" × 9'-1". The laundry room (8'-8" × 5'-5") and the 12'-9" × 17'-2" one-car garage complete the plan.
Layout highlights
- Living room of 11'-11" × 21'-2" is the largest room and anchors the open plan.
- Kitchen (8'-8" × 12'-9") and dining (8'-8" × 10'-11") sit beside the living room.
- Primary suite pairs a 10'-8" × 11'-11" bedroom with a 6'-0" × 9'-1" private bath.
- Bedroom 2 (10'-8" × 9'-8") shares the hall bath, 6'-0" × 6'-10", across the bedroom hall.
- Laundry room of 8'-8" × 5'-5" and a 12'-9" × 17'-2" garage handle daily utility needs.
Room sizes
| Room | Size | Area |
|---|---|---|
| Dining | 8'-8" × 10'-11" | 95 sq ft |
| Kitchen | 8'-8" × 12'-9" | 110 sq ft |
| Laundry | 8'-8" × 5'-5" | 47 sq ft |
| Living Room | 11'-11" × 21'-2" | 252 sq ft |
| Garage | 12'-9" × 17'-2" | 219 sq ft |
| Bedroom 2 | 10'-8" × 9'-8" | 103 sq ft |
| Bedroom Hall | 4'-2" × 16'-4" | 69 sq ft |
| Hall Bath | 6'-0" × 6'-10" | 41 sq ft |
| Primary Bath | 6'-0" × 9'-1" | 55 sq ft |
| Primary Bedroom | 10'-8" × 11'-11" | 127 sq ft |
Who this plan suits
This plan suits couples, singles, downsizers or small households who want two bedrooms and two baths on one level with no stairs. It needs a lot that fits the 34'-9" × 40'-8" footprint plus setbacks, with room for a front porch and a driveway to the one-car garage.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Single-story house, 2 bedrooms, 2 baths, open kitchen, dining and living, laundry, attached 1-car garage, front porch, about 1,100 sq ft of living space (garage not included).” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What should I look for in 1100 sq ft house plans?
Look for a compact footprint where little space is lost to hallways. This plan has 1,090 sq ft of living space on one level, with a single 4'-2" × 16'-4" hall serving the bedrooms. The garage is not counted in that figure.
What affects the lot and building cost of this plan?
The 34'-9" × 40'-8" footprint sets the minimum lot width and depth once setbacks are added. Cost depends on your region, foundation type, finishes and the attached garage, so get local quotes before you commit. A single story with a simple footprint keeps the structure straightforward.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as resizing rooms, moving the garage to the other side or fitting a narrower lot, and the plan is regenerated. Check the new room sizes and footprint after each change.
How do I use the PDF, DXF and IFC files?
The PDF is for reviewing and sharing the drawings. The DXF opens in CAD software for further drafting, and the IFC imports into BIM tools. Have a local architect or engineer review the plan before you apply for a permit.
