This one-story plan has a 61'-0" × 43'-0" footprint and 1,900 sq ft of living space, not counting the carport. The entry foyer (10'-4" × 7'-2") leads to a living room that runs 35'-3" by 12'-2". The dining area (11'-5" × 12'-2") and the galley kitchen (11'-7" × 12'-11") sit alongside it. A wall of glass faces the back patio, so the main rooms share the same view.
The three bedrooms are grouped off an 11'-9" × 8'-10" bedroom hall. Bedrooms 2 and 3 are about 10'-9" × 10'-11". The primary bedroom is 10'-11" × 16'-4", with a 7'-10" × 7'-2" walk-in closet and a 7'-8" × 10'-11" bath. A 6'-4" × 8'-10" hall bath serves the other two bedrooms. The laundry (8'-4" × 6'-2") and mudroom (7'-4" × 6'-2") support the entry from the 2-car carport (16'-1" × 21'-2").
Layout highlights
- Living room spans 35'-3" × 12'-2" and opens through glass to the back patio.
- Galley kitchen at 11'-7" × 12'-11" sits beside the 11'-5" × 12'-2" dining area.
- Primary suite combines a 10'-11" × 16'-4" bedroom, 7'-10" × 7'-2" walk-in closet, and private bath.
- Bedrooms 2 and 3 are about 10'-9" × 10'-11" and share a 6'-4" × 8'-10" hall bath.
- Mudroom (7'-4" × 6'-2") and laundry (8'-4" × 6'-2") sit at the 16'-1" × 21'-2" carport.
Room sizes
| Room | Size | Area |
|---|---|---|
| Bedroom 3 | 10'-8" × 10'-11" | 116 sq ft |
| Bedroom 2 | 10'-9" × 10'-11" | 118 sq ft |
| Primary Bath | 7'-8" × 10'-11" | 84 sq ft |
| Hall Bath | 6'-4" × 8'-10" | 56 sq ft |
| Bedroom Hall | 11'-9" × 8'-10" | 103 sq ft |
| Entry Foyer | 10'-4" × 7'-2" | 74 sq ft |
| Walk-in Closet | 7'-10" × 7'-2" | 56 sq ft |
| Primary Bedroom | 10'-11" × 16'-4" | 179 sq ft |
| 2-Car Carport | 16'-1" × 21'-2" | 340 sq ft |
| Laundry | 8'-4" × 6'-2" | 51 sq ft |
| Mudroom | 7'-4" × 6'-2" | 45 sq ft |
| Living Room | 35'-3" × 12'-2" | 428 sq ft |
| Dining | 11'-5" × 12'-2" | 139 sq ft |
| Galley Kitchen | 11'-7" × 12'-11" | 150 sq ft |
Who this plan suits
This plan suits households that want single-level living with a clear split between the open living area and the bedroom wing. It needs a lot that fits the 61'-0" × 43'-0" footprint, plus room for the back patio and carport access.
How this plan was made
It was generated in AI Architectures Plan Studio from this one-line brief: “Mid-century modern one-story house, low-slope roof, 3 bedrooms, 2 baths, open living and dining with a wall of glass to the back patio, galley kitchen, laundry, carport-style 2-car garage, about 1,900 sq ft of living space.” An AI architect drafted the room program, a layout solver placed every wall and door, and the plan was checked automatically for room sizes, circulation and daylight. The same project produced the PDF sheets, layered DXF, IFC model and 3D model you can download above.
Frequently asked questions
What are mid century modern house plans?
Mid century modern house plans typically use low-slope roofs, simple horizontal massing, and large areas of glass that connect indoor rooms to the outdoors. This version is a one-story layout with an open living and dining space, a galley kitchen, and a glazed wall facing the back patio.
What affects the lot and building cost of this plan?
The 61'-0" × 43'-0" footprint sets the minimum lot width and depth, and the single-story form spreads the foundation and roof over a larger area. The glazed patio wall, the 1,900 sq ft of living space, and the carport structure are also main cost drivers. Local site conditions, finishes, and labor rates will change the final figure.
Can I change this plan by chat?
Yes. You can describe changes in chat, such as resizing rooms, moving the carport to the other side, or fitting the plan to a narrower lot. The layout is then regenerated so the rooms still connect properly.
How do I use the PDF, DXF, and IFC files?
The PDF is for reading and sharing the plan with builders, lenders, or permit staff. The DXF opens in CAD software for editing the 2D drawings, and the IFC loads into BIM tools for a 3D model. Have a local licensed professional review the plans before you apply for a permit.
